Megadyne Gold 3600GLD2-8M30 Timing Belt, 8M

Save $ 73.53

Price:
$ 336.69 $ 410.22

Description

Megadyne Gold 3600GLD2-8M30 Timing Belt, 8M

The Megadyne MEGASYNC 3600GLD2-8M30 is a Gold curvilinear (HTD/RPP) synchronous timing belt with a 8M (8mm-pitch) tooth, a 3600 mm pitch length, and a 30mm width, 450 teeth. It delivers positive, slip-free power transmission for industrial drives where shaft timing matters. It replaces the equivalent Jason Industrial 3600GLD2-8M30.

Specification Value
Part Number 3600GLD2-8M30
Profile / Pitch 8M
Construction Rubber/Fiberglass
Tooth Profile Curvilinear (HTD/RPP)
Width 30mm
Thickness 5.6mm
Pitch Length 3600 mm
Number of Teeth 450
Performance Tier Gold
Temperature Range -13°F to 176°F

Applications

  • Conveyors and material handling
  • Pumps, mixers, and packaging machinery
  • Machine tools requiring shaft synchronization
  • Quiet, lubrication-free alternatives to chain or gear drives

Cross-References

The 8M curvilinear profile interchanges by pitch, length, and width with Gates PowerGrip GT3/HTD 8M, Continental Synchroforce 8M, Dayco 3600GLD2-8M30, and Jason Industrial 3600GLD2-8M30. Runs on standard 8M (HTD) sprockets. See the timing belts collection.

Frequently Asked Questions

What is the Megadyne 3600GLD2-8M30 used for?

The 3600GLD2-8M30 is used for conveyors and material handling, such as pumps, mixers, and packaging machinery and machine tools requiring shaft synchronization.

What are the dimensions of 3600GLD2-8M30?

The 3600GLD2-8M30 has a 30mm width, a 3600 mm pitch length, 450 teeth in the 8M profile.

Is 3600GLD2-8M30 interchangeable with Gates 8M belts?

Yes. The 8M curvilinear tooth, length, and width match Gates PowerGrip GT/HTD, Continental, and Dayco belts of the same size, all running on standard 8M (HTD) sprockets.

What is the temperature rating of 3600GLD2-8M30?

The 3600GLD2-8M30 is rated for continuous operation from -13°F to 176°F.

Does 3600GLD2-8M30 ship from Houston?

Yes. The 3600GLD2-8M30 ships from the Texas Belting & Supply warehouse in Houston, TX, with same-day shipping on stock items. Call (888) 203-2358 for stock and lead time.
