Megadyne Platinum 4000PLT8M60 Timing Belt, 8M

Save $ 178.20

Price:
$ 815.92 $ 994.12

Description

Megadyne Platinum 4000PLT8M60 Timing Belt, 8M

The Megadyne MEGASYNC 4000PLT8M60 is a Platinum curvilinear (HTD/RPP) synchronous timing belt with a 8M (8mm-pitch) tooth, a 4000 mm pitch length, and a 60mm width, 500 teeth. It delivers positive, slip-free power transmission for industrial drives where shaft timing matters. It replaces the equivalent Jason Industrial 4000PLT8M60.

Specification Value
Part Number 4000PLT8M60
Profile / Pitch 8M
Construction Rubber/Fiberglass
Tooth Profile Curvilinear (HTD/RPP)
Width 60mm
Thickness 5.6mm
Pitch Length 4000 mm
Number of Teeth 500
Performance Tier Platinum
Temperature Range -13°F to 176°F

Applications

  • Conveyors and material handling
  • Pumps, mixers, and packaging machinery
  • Machine tools requiring shaft synchronization
  • Quiet, lubrication-free alternatives to chain or gear drives

Cross-References

The 8M curvilinear profile interchanges by pitch, length, and width with Gates PowerGrip GT3/HTD 8M, Continental Synchroforce 8M, Dayco 4000PLT8M60, and Jason Industrial 4000PLT8M60. Runs on standard 8M (HTD) sprockets. See the timing belts collection.

Frequently Asked Questions

What is the Megadyne 4000PLT8M60 used for?

The 4000PLT8M60 is used for conveyors and material handling, such as pumps, mixers, and packaging machinery and machine tools requiring shaft synchronization.

What are the dimensions of 4000PLT8M60?

The 4000PLT8M60 has a 60mm width, a 4000 mm pitch length, 500 teeth in the 8M profile.

Is 4000PLT8M60 interchangeable with Gates 8M belts?

Yes. The 8M curvilinear tooth, length, and width match Gates PowerGrip GT/HTD, Continental, and Dayco belts of the same size, all running on standard 8M (HTD) sprockets.

What is the temperature rating of 4000PLT8M60?

The 4000PLT8M60 is rated for continuous operation from -13°F to 176°F.

Does 4000PLT8M60 ship from Houston?

Yes. The 4000PLT8M60 ships from the Texas Belting & Supply warehouse in Houston, TX, with same-day shipping on stock items. Call (888) 203-2358 for stock and lead time.

Need a quote on 4000PLT8M60?

Houston warehouse, same-day shipping on stock items.

Call (888) 203-2358
