Megadyne Silver 45.5M-SLV Timing Belt, 5M

Save $ 0.93

Price:
$ 33.34 $ 34.27

Description

Megadyne Silver 45.5M-SLV Timing Belt, 5M

The Megadyne MEGASYNC 45.5M-SLV is a Silver curvilinear (HTD/RPP) synchronous timing belt with a 5M (5mm-pitch) tooth, a 45 mm pitch length, and a width, 9 teeth. It delivers positive, slip-free power transmission for industrial drives where shaft timing matters. It replaces the equivalent Jason Industrial 45.5M-SLV.

$35 minimum order on Megadyne belts. Mix and match any Megadyne belts in your cart to reach the $35 minimum. Questions? Call (888) 203-2358.

Specification Value
Part Number 45.5M-SLV
Profile / Pitch 5M
Construction Rubber/Fiberglass
Tooth Profile Curvilinear (HTD/RPP)
Thickness 3.6mm
Pitch Length 45 mm
Number of Teeth 9
Performance Tier Silver
Temperature Range -13°F to 176°F

Applications

  • Conveyors and material handling
  • Pumps, mixers, and packaging machinery
  • Machine tools requiring shaft synchronization
  • Quiet, lubrication-free alternatives to chain or gear drives

Cross-References

The 5M curvilinear profile interchanges by pitch, length, and width with Gates PowerGrip GT3/HTD 5M, Continental Synchroforce 5M, Dayco 45.5M-SLV, and Jason Industrial 45.5M-SLV. Runs on standard 5M (HTD) sprockets. See the timing belts collection.

Frequently Asked Questions

What is the Megadyne 45.5M-SLV used for?

The 45.5M-SLV is used for conveyors and material handling, such as pumps, mixers, and packaging machinery and machine tools requiring shaft synchronization.

What are the dimensions of 45.5M-SLV?

The 45.5M-SLV has a 45 mm pitch length, 9 teeth in the 5M profile.

Is 45.5M-SLV interchangeable with Gates 5M belts?

Yes. The 5M curvilinear tooth, length, and width match Gates PowerGrip GT/HTD, Continental, and Dayco belts of the same size, all running on standard 5M (HTD) sprockets.

What is the temperature rating of 45.5M-SLV?

The 45.5M-SLV is rated for continuous operation from -13°F to 176°F.

Does 45.5M-SLV ship from Houston?

Yes. The 45.5M-SLV ships from the Texas Belting & Supply warehouse in Houston, TX, with same-day shipping on stock items. Call (888) 203-2358 for stock and lead time.

Need a quote on 45.5M-SLV?

Houston warehouse, same-day shipping on stock items.

Call (888) 203-2358
