Megadyne Silver 500SLV3-5M32 Timing Belt, 5M
The Megadyne MEGASYNC 500SLV3-5M32 is a Silver curvilinear (HTD/RPP) synchronous timing belt with a 5M (5mm-pitch) tooth, a 500 mm pitch length, and a 32mm width, 100 teeth. It delivers positive, slip-free power transmission for industrial drives where shaft timing matters. It replaces the equivalent Jason Industrial 500SLV3-5M32.
| Specification | Value |
|---|---|
| Part Number | 500SLV3-5M32 |
| Profile / Pitch | 5M |
| Construction | Rubber/Fiberglass |
| Tooth Profile | Curvilinear (HTD/RPP) |
| Width | 32mm |
| Thickness | 3.6mm |
| Pitch Length | 500 mm |
| Number of Teeth | 100 |
| Performance Tier | Silver |
| Temperature Range | -13°F to 176°F |
Applications
- Conveyors and material handling
- Pumps, mixers, and packaging machinery
- Machine tools requiring shaft synchronization
- Quiet, lubrication-free alternatives to chain or gear drives
Cross-References
The 5M curvilinear profile interchanges by pitch, length, and width with Gates PowerGrip GT3/HTD 5M, Continental Synchroforce 5M, Dayco 500SLV3-5M32, and Jason Industrial 500SLV3-5M32. Runs on standard 5M (HTD) sprockets. See the timing belts collection.
Frequently Asked Questions
What is the Megadyne 500SLV3-5M32 used for?
The 500SLV3-5M32 is used for conveyors and material handling, such as pumps, mixers, and packaging machinery and machine tools requiring shaft synchronization.
What are the dimensions of 500SLV3-5M32?
The 500SLV3-5M32 has a 32mm width, a 500 mm pitch length, 100 teeth in the 5M profile.
Is 500SLV3-5M32 interchangeable with Gates 5M belts?
Yes. The 5M curvilinear tooth, length, and width match Gates PowerGrip GT/HTD, Continental, and Dayco belts of the same size, all running on standard 5M (HTD) sprockets.
What is the temperature rating of 500SLV3-5M32?
The 500SLV3-5M32 is rated for continuous operation from -13°F to 176°F.
Does 500SLV3-5M32 ship from Houston?
Yes. The 500SLV3-5M32 ships from the Texas Belting & Supply warehouse in Houston, TX, with same-day shipping on stock items. Call (888) 203-2358 for stock and lead time.
Need a quote on 500SLV3-5M32?
Houston warehouse, same-day shipping on stock items.
