Megadyne Silver 750SLV3-5M25 Timing Belt, 5M

Save $ 11.33

Price:
$ 51.89 $ 63.22

Description

Megadyne Silver 750SLV3-5M25 Timing Belt, 5M

The Megadyne MEGASYNC 750SLV3-5M25 is a Silver curvilinear (HTD/RPP) synchronous timing belt with a 5M (5mm-pitch) tooth, a 750 mm pitch length, and a 25mm width, 150 teeth. It delivers positive, slip-free power transmission for industrial drives where shaft timing matters. It replaces the equivalent Jason Industrial 750SLV3-5M25.

Specification Value
Part Number 750SLV3-5M25
Profile / Pitch 5M
Construction Rubber/Fiberglass
Tooth Profile Curvilinear (HTD/RPP)
Width 25mm
Thickness 3.6mm
Pitch Length 750 mm
Number of Teeth 150
Performance Tier Silver
Temperature Range -13°F to 176°F

Applications

  • Conveyors and material handling
  • Pumps, mixers, and packaging machinery
  • Machine tools requiring shaft synchronization
  • Quiet, lubrication-free alternatives to chain or gear drives

Cross-References

The 5M curvilinear profile interchanges by pitch, length, and width with Gates PowerGrip GT3/HTD 5M, Continental Synchroforce 5M, Dayco 750SLV3-5M25, and Jason Industrial 750SLV3-5M25. Runs on standard 5M (HTD) sprockets. See the timing belts collection.

Frequently Asked Questions

What is the Megadyne 750SLV3-5M25 used for?

The 750SLV3-5M25 is used for conveyors and material handling, such as pumps, mixers, and packaging machinery and machine tools requiring shaft synchronization.

What are the dimensions of 750SLV3-5M25?

The 750SLV3-5M25 has a 25mm width, a 750 mm pitch length, 150 teeth in the 5M profile.

Is 750SLV3-5M25 interchangeable with Gates 5M belts?

Yes. The 5M curvilinear tooth, length, and width match Gates PowerGrip GT/HTD, Continental, and Dayco belts of the same size, all running on standard 5M (HTD) sprockets.

What is the temperature rating of 750SLV3-5M25?

The 750SLV3-5M25 is rated for continuous operation from -13°F to 176°F.

Does 750SLV3-5M25 ship from Houston?

Yes. The 750SLV3-5M25 ships from the Texas Belting & Supply warehouse in Houston, TX, with same-day shipping on stock items. Call (888) 203-2358 for stock and lead time.

Need a quote on 750SLV3-5M25?

Houston warehouse, same-day shipping on stock items.

Call (888) 203-2358
