Megadyne 7MR600 NEOFLEX Wide-Angle V-Belt, 7M

Save $ 26.01

Price:
$ 18.04 $ 44.05

Description

Megadyne 7MR600 NEOFLEX Wide-Angle V-Belt, 7M

The Megadyne 7MR600 is a NEOFLEX 60-degree wide-angle V-belt with a 7mm (7M) top width and a 600 mm effective length. Its wide 60-degree angle provides more sidewall support under the tensile member than a conventional V-belt, distributing load evenly for higher power ratings and allowing maximum speed ratios on smaller pulleys. The belt is constructed from a chloroprene (Neoprene) body with transverse fabric plies for rigidity and a polyester tensile member. It replaces the equivalent Jason Industrial 7MR600.

$35 minimum order on Megadyne belts. Mix and match any Megadyne belts in your cart to reach the $35 minimum. Questions? Call (888) 203-2358.

Specification Value
Part Number 7MR600
Cross Section 7M
Construction Chloroprene body, transverse fabric plies
Top Width 7mm
Belt Angle 60°
Thickness 5mm
Effective Length 600 mm
Temperature Range -22°F to 176°F

Applications

  • Compact high-ratio drives with small pulleys
  • Power tools, machine tools, and centrifugal pumps
  • Lawn & garden and outdoor power equipment
  • High-speed fractional and integral HP drives

Cross-References

The 7MR600 is the direct continuation of the Jason Industrial 7MR600 NEOFLEX belt, now produced under the Megadyne brand. Replace any Jason Industrial 7MR600 with this belt one-for-one. Browse the full V-belt collection.

Frequently Asked Questions

What is the Megadyne 7MR600 used for?

The 7MR600 is used for compact high-ratio drives with small pulleys, such as power tools, machine tools, and centrifugal pumps.

What does the 60-degree angle do?

The wide 60-degree angle gives the 7MR600 more sidewall support under the tensile member than a standard 40-degree V-belt, which distributes load evenly and allows higher speed ratios on smaller pulleys.

What are the dimensions of 7MR600?

The 7MR600 has a 7mm (7M) top width, a 5mm depth, and a 600 mm effective length.

Does 7MR600 replace the Jason Industrial 7MR600?

Yes. The 7MR600 is the same NEOFLEX belt formerly sold under the Jason Industrial brand, now produced by Megadyne. It is a one-for-one replacement.

Does 7MR600 ship from Houston?

Yes. The 7MR600 ships from the Texas Belting & Supply warehouse in Houston, TX, with same-day shipping on stock items. Call (888) 203-2358 for availability.

Need a quote on 7MR600?

Houston warehouse, same-day shipping on stock items.
