Megadyne Silver 800SLV3-5M26 Timing Belt, 5M
The Megadyne MEGASYNC 800SLV3-5M26 is a Silver curvilinear (HTD/RPP) synchronous timing belt with a 5M (5mm-pitch) tooth, a 800 mm pitch length, and a 26mm width, 160 teeth. It delivers positive, slip-free power transmission for industrial drives where shaft timing matters. It replaces the equivalent Jason Industrial 800SLV3-5M26.
| Specification | Value |
|---|---|
| Part Number | 800SLV3-5M26 |
| Profile / Pitch | 5M |
| Construction | Rubber/Fiberglass |
| Tooth Profile | Curvilinear (HTD/RPP) |
| Width | 26mm |
| Thickness | 3.6mm |
| Pitch Length | 800 mm |
| Number of Teeth | 160 |
| Performance Tier | Silver |
| Temperature Range | -13°F to 176°F |
Applications
- Conveyors and material handling
- Pumps, mixers, and packaging machinery
- Machine tools requiring shaft synchronization
- Quiet, lubrication-free alternatives to chain or gear drives
Cross-References
The 5M curvilinear profile interchanges by pitch, length, and width with Gates PowerGrip GT3/HTD 5M, Continental Synchroforce 5M, Dayco 800SLV3-5M26, and Jason Industrial 800SLV3-5M26. Runs on standard 5M (HTD) sprockets. See the timing belts collection.
Frequently Asked Questions
What is the Megadyne 800SLV3-5M26 used for?
The 800SLV3-5M26 is used for conveyors and material handling, such as pumps, mixers, and packaging machinery and machine tools requiring shaft synchronization.
What are the dimensions of 800SLV3-5M26?
The 800SLV3-5M26 has a 26mm width, a 800 mm pitch length, 160 teeth in the 5M profile.
Is 800SLV3-5M26 interchangeable with Gates 5M belts?
Yes. The 5M curvilinear tooth, length, and width match Gates PowerGrip GT/HTD, Continental, and Dayco belts of the same size, all running on standard 5M (HTD) sprockets.
What is the temperature rating of 800SLV3-5M26?
The 800SLV3-5M26 is rated for continuous operation from -13°F to 176°F.
Does 800SLV3-5M26 ship from Houston?
Yes. The 800SLV3-5M26 ships from the Texas Belting & Supply warehouse in Houston, TX, with same-day shipping on stock items. Call (888) 203-2358 for stock and lead time.
Need a quote on 800SLV3-5M26?
Houston warehouse, same-day shipping on stock items.
