Description
Megadyne Gold 950GLD2-5M09 Timing Belt, 5M
The Megadyne MEGASYNC 950GLD2-5M09 is a Gold curvilinear (HTD/RPP) synchronous timing belt with a 5M (5mm-pitch) tooth, a 950 mm pitch length, and a 09mm width, 190 teeth. It delivers positive, slip-free power transmission for industrial drives where shaft timing matters. It replaces the equivalent Jason Industrial 950GLD2-5M09.
| Specification | Value |
|---|---|
| Part Number | 950GLD2-5M09 |
| Profile / Pitch | 5M |
| Construction | Rubber/Fiberglass |
| Tooth Profile | Curvilinear (HTD/RPP) |
| Width | 09mm |
| Thickness | 3.6mm |
| Pitch Length | 950 mm |
| Number of Teeth | 190 |
| Performance Tier | Gold |
| Temperature Range | -13°F to 176°F |
Applications
- Conveyors and material handling
- Pumps, mixers, and packaging machinery
- Machine tools requiring shaft synchronization
- Quiet, lubrication-free alternatives to chain or gear drives
Cross-References
The 5M curvilinear profile interchanges by pitch, length, and width with Gates PowerGrip GT3/HTD 5M, Continental Synchroforce 5M, Dayco 950GLD2-5M09, and Jason Industrial 950GLD2-5M09. Runs on standard 5M (HTD) sprockets. See the timing belts collection.
Frequently Asked Questions
What is the Megadyne 950GLD2-5M09 used for?
The 950GLD2-5M09 is used for conveyors and material handling, such as pumps, mixers, and packaging machinery and machine tools requiring shaft synchronization.
What are the dimensions of 950GLD2-5M09?
The 950GLD2-5M09 has a 09mm width, a 950 mm pitch length, 190 teeth in the 5M profile.
Is 950GLD2-5M09 interchangeable with Gates 5M belts?
Yes. The 5M curvilinear tooth, length, and width match Gates PowerGrip GT/HTD, Continental, and Dayco belts of the same size, all running on standard 5M (HTD) sprockets.
What is the temperature rating of 950GLD2-5M09?
The 950GLD2-5M09 is rated for continuous operation from -13°F to 176°F.
Does 950GLD2-5M09 ship from Houston?
Yes. The 950GLD2-5M09 ships from the Texas Belting & Supply warehouse in Houston, TX, with same-day shipping on stock items. Call (888) 203-2358 for stock and lead time.
Need a quote on 950GLD2-5M09?
Houston warehouse, same-day shipping on stock items.
