Bando 250-DS8M-4400 8M DS Double-Sided STS Timing Belt
The Bando 250-DS8M-4400 is a 8M ds double-sided sts timing belt with a 4400.0 mm (173.23 in) pitch length, 25.0 mm (0.98 in) width, and 550 teeth. Built on a neoprene body with fiberglass cords, it delivers zero-slip, fixed-ratio synchronous power transmission. Stocked for maintenance, reliability, and procurement teams.
| Specification | Value |
|---|---|
| Part Number | 250-DS8M-4400 |
| Belt Type | DS Double-Sided STS Timing Belt |
| Pitch (Section) | 8 mm (8M) |
| Pitch Length | 4400.0 mm (173.23 in) |
| Number of Teeth | 550 |
| Top Width | 25.0 mm (0.98 in) |
| Thickness | 7.3 mm (0.29 in) |
| Body Material | Neoprene |
| Tension Cord | Fiberglass |
| Construction | Synchronous (curvilinear) |
| Brand | Bando |
Applications
- High-torque synchronous drives requiring zero slip and fixed timing
- Industrial pumps, blowers, and compressors
- Conveyor and material-handling drive systems
- Machine tools, packaging equipment, and process machinery
Frequently Asked Questions
What is the Bando 250-DS8M-4400 used for?
It is a 8M ds double-sided sts timing belt that delivers zero-slip, fixed-ratio synchronous power transmission. Typical uses include high-torque synchronous drives requiring zero slip and fixed timing and industrial pumps, blowers, and compressors.
What is the pitch and tooth count of 250-DS8M-4400?
The belt has a 8 mm tooth pitch, a 4400.0 mm (173.23 in) pitch length, and 550 teeth.
How is the Bando 250-DS8M-4400 constructed?
It uses neoprene construction with fiberglass tension cords in a synchronous (curvilinear) design.
Does 250-DS8M-4400 ship from Houston?
Yes. In-stock belts ship from our Houston, TX warehouse, typically same day on stock items.
