105V1500J V-Belt Sheave, 1 Groove, 5V Section, 15 in OD, J Bushing


Price:
$ 1,108.76

Description

105V1500J V-Belt Sheave, 1 Groove, 5V Section, 15 in OD, J Bushing

The 105V1500J is a 1-groove 5V section narrow wedge V-belt sheave with a 15 in outside diameter, fully machined from cast iron and statically balanced. It mounts with an industry-standard J QD® style bushing, sold separately, sized to your shaft. It runs 5V and 5VX narrow wedge V-belts.

Specifications

Specification Value
Part Number 105V1500J
Belt Section 5V
Grooves 1
Outside Diameter 15 in
Pitch Diameter 14.9 in
Face Width 7.1875 in
Bushing J series, QD® style (not included)
Material Cast Iron, fully machined, statically balanced
Weight 138 lb
Country of Origin China

Applications

  • Multi-belt narrow wedge drives on fans, blowers, and pumps
  • HVAC air handlers and cooling tower drives
  • Compressors and industrial process equipment
  • Replacing worn sheaves on existing drives without changing belts or bushings

Cross Reference

The 105V1500J interchanges with these equivalent part numbers, per published manufacturer interchange data:

Manufacturer Equivalent Part Number
Dodge® D10-5V150
Martin 10 5V 1500 J
Gates® QD10/5V15.00
TB Woods® 5V15010
Regal Rexnord (Browning®) 105V1500J
Carlisle 10-5V-1500-J
Masterdrive 10/5V1500J
Maurey 105V15.0-J
Jason Industrial 10/5V1500J
Optibelt QD 5V1500/10 J

Always verify dimensions and bore size before substituting part numbers across manufacturers.

Buying in bulk? Save on volume.

Multi-unit and OEM quantities qualify for volume discounts. Call or email for a quantity quote.

Frequently Asked Questions

What belts run on the 105V1500J?

5V and 5VX narrow wedge V-belts. These sections are standardized, so any manufacturer's belts of the correct section and length will run in the grooves.

Does the 105V1500J replace the Dodge D10-5V150 sheave?

Yes. Published interchange data crosses the 105V1500J directly to the Dodge D10-5V150, as well as Martin 10 5V 1500 J, Gates QD10/5V15.00, TB Woods 5V15010. Verify groove count, diameter, and bore or bushing before ordering.

What bushing does the 105V1500J use?

A J series QD style bushing, sold separately. J is an industry-standard bushing size, so any manufacturer's standard J bushing fits. Order the bushing bore that matches your shaft diameter.

Does the 105V1500J ship from Houston?

Yes. Stock items ship same day from our Houston, Texas warehouse. Call (888) 203-2358 to confirm availability.

Need a quote on 105V1500J?

Houston warehouse, same-day shipping on stock items.

Call (888) 203-2358

QD® is a registered trademark of TB Woods/Regal Rexnord. All third-party part numbers and trademarks referenced, including Dodge®, Gates®, Martin, TB Woods®, Browning®, and others shown in the cross reference table, are the property of their respective owners. References are for compatibility identification only and do not imply affiliation or endorsement.
