105V3150M V-Belt Sheave, 1 Groove, 5V Section, 31.5 in OD, M Bushing


Price:
$ 2,632.56

Description

105V3150M V-Belt Sheave, 1 Groove, 5V Section, 31.5 in OD, M Bushing

The 105V3150M is a 1-groove 5V section narrow wedge V-belt sheave with a 31.5 in outside diameter, fully machined from cast iron and statically balanced. It mounts with an industry-standard M QD® style bushing, sold separately, sized to your shaft. It runs 5V and 5VX narrow wedge V-belts.

Specifications

Specification Value
Part Number 105V3150M
Belt Section 5V
Grooves 1
Outside Diameter 31.5 in
Pitch Diameter 31.4 in
Face Width 7.1875 in
Bushing M series, QD® style (not included)
Material Cast Iron, fully machined, statically balanced
Weight 275 lb
Country of Origin China

Applications

  • Multi-belt narrow wedge drives on fans, blowers, and pumps
  • HVAC air handlers and cooling tower drives
  • Compressors and industrial process equipment
  • Replacing worn sheaves on existing drives without changing belts or bushings

Cross Reference

The 105V3150M interchanges with these equivalent part numbers, per published manufacturer interchange data:

Manufacturer Equivalent Part Number
Dodge® D10-5V315
Martin 10 5V 3150 M
Gates® QD10/5V31.50
TB Woods® 5V31510
Regal Rexnord (Browning®) 105V3150M
Carlisle 10-5V-3150-M
Masterdrive 10/5V3150M
Maurey 105V31.5-M
Jason Industrial 10/5V3150M
Optibelt QD 5V3150/10 M

Always verify dimensions and bore size before substituting part numbers across manufacturers.

Buying in bulk? Save on volume.

Multi-unit and OEM quantities qualify for volume discounts. Call or email for a quantity quote.

Frequently Asked Questions

What belts run on the 105V3150M?

5V and 5VX narrow wedge V-belts. These sections are standardized, so any manufacturer's belts of the correct section and length will run in the grooves.

Does the 105V3150M replace the Dodge D10-5V315 sheave?

Yes. Published interchange data crosses the 105V3150M directly to the Dodge D10-5V315, as well as Martin 10 5V 3150 M, Gates QD10/5V31.50, TB Woods 5V31510. Verify groove count, diameter, and bore or bushing before ordering.

What bushing does the 105V3150M use?

A M series QD style bushing, sold separately. M is an industry-standard bushing size, so any manufacturer's standard M bushing fits. Order the bushing bore that matches your shaft diameter.

Does the 105V3150M ship from Houston?

Yes. Stock items ship same day from our Houston, Texas warehouse. Call (888) 203-2358 to confirm availability.

Need a quote on 105V3150M?

Houston warehouse, same-day shipping on stock items.

Call (888) 203-2358

QD® is a registered trademark of TB Woods/Regal Rexnord. All third-party part numbers and trademarks referenced, including Dodge®, Gates®, Martin, TB Woods®, Browning®, and others shown in the cross reference table, are the property of their respective owners. References are for compatibility identification only and do not imply affiliation or endorsement.
