Description
10XL025M6FA6 Timing Pulley, 1 Teeth, XL Pitch, 6 mm Bore
The 10XL025M6FA6 is a 1-tooth XL (0.200 in trapezoidal) timing pulley with a 6 mm finished bore, machined from aluminum with a clear anodized finish, built for 0.25 in wide belts. Machined from solid stock, never sintered or powdered metal.
$50 minimum order on drive components. Mix and match any pulleys, bushings, sheaves, sprockets, and accessories in your cart to reach the $50 minimum. Questions? Call (888) 203-2358.
Specifications

Dimension key for this construction type. Values for this part number are in the table below.
| Specification | Value |
|---|---|
| Part Number | 10XL025M6FA6 |
| Teeth | 1 |
| Pitch | XL (0.200 in trapezoidal) |
| For Belt Width | 0.25 in |
| Pitch Diameter | 0.6366 in |
| Outside Diameter | 0.6166 in |
| Flange Diameter | 0.875 in |
| Bore | 6 mm finished bore |
| Construction | Standard Hub |
| Set Screws | 1 x M3 |
| Flange Material | Aluminum |
| Material | Aluminum (no sintered or powdered metal) |
| Finish | Clear Anodized |
| Weight | 0.0158 lb |
| Country of Origin | India |
Applications
- Instrumentation, office equipment, and precision positioning drives
- 3D printers and desktop CNC equipment
- Robotics, medical devices, and packaging machinery
Belt Compatibility
The 10XL025M6FA6 runs XL (0.200 in trapezoidal) belts in 0.25 in width. The pitch is standardized, so belt and pulley brands can be mixed.
Cross Reference
The 10XL025M6FA6 interchanges with these equivalent part numbers, per published manufacturer interchange data:
| Manufacturer | Equivalent Part Number |
|---|---|
| Mitsuboshi | 10XL025M6FA6 |
| Stock Drive Products (SDP/SI) | A 6A 3M010DF06006 |
| McMaster-Carr | 1277N711 |
| Powerdrive | 10XL025M6FA6 |
Always verify dimensions and bore size before substituting part numbers across manufacturers.
Buying in bulk? Save on volume.
Multi-unit and OEM quantities qualify for volume discounts. Call or email for a quantity quote.
Frequently Asked Questions
What belts fit the 10XL025M6FA6 pulley?
XL (0.200 in trapezoidal) timing belts in 0.25 in width from any manufacturer. The pitch is standardized, so belt and pulley brands can be mixed.
Does the 10XL025M6FA6 replace the Mitsuboshi 10XL025M6FA6?
Yes. Published interchange data crosses the 10XL025M6FA6 directly to the Mitsuboshi 10XL025M6FA6, as well as Stock Drive Products A 6A 3M010DF06006, McMaster-Carr 1277N711, Powerdrive 10XL025M6FA6. Verify dimensions and bore before ordering.
Does the 10XL025M6FA6 ship from Houston?
Yes. Stock items ship same day from our Houston, Texas warehouse. Call (888) 203-2358 to confirm availability.
