Description
110MP025-DFM4 Timing Pulley, 11 Teeth, MXL Pitch
The 110MP025-DFM4 is a 11-tooth MXL (0.080 in trapezoidal) timing pulley with a 5/16 in Bore, machined from polycarbonate, built for 0.25 in wide belts. Machined from solid stock, never sintered or powdered metal.
$50 minimum order on drive components. Mix and match any pulleys, bushings, sheaves, sprockets, and accessories in your cart to reach the $50 minimum. Questions? Call (888) 203-2358.
Specifications
| Specification | Value |
|---|---|
| Part Number | 110MP025-DFM4 |
| Teeth | 11 |
| Pitch | MXL (0.080 in trapezoidal) |
| For Belt Width | 0.25 in |
| Pitch Diameter | 2.8011 in |
| Outside Diameter | 2.7811 in |
| Flange Diameter | 2.97 in |
| Bore | 5/16 in Bore |
| Face Width | 0.433 in |
| Overall Length | 0.688 in |
| Hub Diameter | 0.6875 in |
| Set Screws | 1 x 8-32 |
| Flange Material | Polycarbonate |
| Material | Polycarbonate (no sintered or powdered metal) |
| Weight | 0.079 lb |
| Country of Origin | United States. ISO 9001:2015 certified manufacturing. |
Applications
- Instrumentation, office equipment, and precision positioning drives
- 3D printers and desktop CNC equipment
- Robotics, medical devices, and packaging machinery
Belt Compatibility
The 110MP025-DFM4 runs MXL (0.080 in trapezoidal) belts in 0.25 in width. The pitch is standardized, so belt and pulley brands can be mixed.
Cross Reference
The 110MP025-DFM4 interchanges with these equivalent part numbers, per published manufacturer interchange data:
| Manufacturer | Equivalent Part Number |
|---|---|
| Plastok | 110T0800DFAH1S |
| Powerdrive | 110MP025-DFM4 |
Always verify dimensions and bore size before substituting part numbers across manufacturers.
Buying in bulk? Save on volume.
Multi-unit and OEM quantities qualify for volume discounts. Call or email for a quantity quote.
Frequently Asked Questions
What belts fit the 110MP025-DFM4 pulley?
MXL (0.080 in trapezoidal) timing belts in 0.25 in width from any manufacturer. The pitch is standardized, so belt and pulley brands can be mixed.
Does the 110MP025-DFM4 replace the Plastok 110T0800DFAH1S?
Yes. Published interchange data crosses the 110MP025-DFM4 directly to the Plastok 110T0800DFAH1S, as well as Powerdrive 110MP025-DFM4. Verify dimensions and bore before ordering.
Does the 110MP025-DFM4 ship from Houston?
Yes. Stock items ship same day from our Houston, Texas warehouse. Call (888) 203-2358 to confirm availability.
Need a quote on 110MP025-DFM4?
Houston warehouse, same-day shipping on stock items.
