Description
110MP025MDFB8 Timing Pulley, 11 Teeth, MXL Pitch
The 110MP025MDFB8 is a 11-tooth MXL (0.080 in trapezoidal) timing pulley with a 8 mm Bore, machined from polycarbonate, built for 0.25 in wide belts. Machined from solid stock, never sintered or powdered metal.
$50 minimum order on drive components. Mix and match any pulleys, bushings, sheaves, sprockets, and accessories in your cart to reach the $50 minimum. Questions? Call (888) 203-2358.
Specifications
| Specification | Value |
|---|---|
| Part Number | 110MP025MDFB8 |
| Teeth | 11 |
| Pitch | MXL (0.080 in trapezoidal) |
| For Belt Width | 0.25 in |
| Pitch Diameter | 2.8011 in |
| Outside Diameter | 2.7811 in |
| Flange Diameter | 2.97 in |
| Bore | 8 mm Bore |
| Face Width | 0.433 in |
| Overall Length | 0.6875 in |
| Hub Diameter | 0.6875 in |
| Set Screws | 1 x M4 |
| Flange Material | Polycarbonate |
| Material | Polycarbonate (no sintered or powdered metal) |
| Weight | 0.07 lb |
| Country of Origin | United States. ISO 9001:2015 certified manufacturing. |
Applications
- Instrumentation, office equipment, and precision positioning drives
- 3D printers and desktop CNC equipment
- Robotics, medical devices, and packaging machinery
Belt Compatibility
The 110MP025MDFB8 runs MXL (0.080 in trapezoidal) belts in 0.25 in width. The pitch is standardized, so belt and pulley brands can be mixed.
Cross Reference
The 110MP025MDFB8 interchanges with these equivalent part numbers, per published manufacturer interchange data:
| Manufacturer | Equivalent Part Number |
|---|---|
| Stock Drive Products (SDP/SI) | A 6Z16M110DF6008 |
| Powerdrive | 110MP025MDFB8 |
Always verify dimensions and bore size before substituting part numbers across manufacturers.
Buying in bulk? Save on volume.
Multi-unit and OEM quantities qualify for volume discounts. Call or email for a quantity quote.
Frequently Asked Questions
What belts fit the 110MP025MDFB8 pulley?
MXL (0.080 in trapezoidal) timing belts in 0.25 in width from any manufacturer. The pitch is standardized, so belt and pulley brands can be mixed.
Does the 110MP025MDFB8 replace the Stock Drive Products A 6Z16M110DF6008?
Yes. Published interchange data crosses the 110MP025MDFB8 directly to the Stock Drive Products A 6Z16M110DF6008, as well as Powerdrive 110MP025MDFB8. Verify dimensions and bore before ordering.
Does the 110MP025MDFB8 ship from Houston?
Yes. Stock items ship same day from our Houston, Texas warehouse. Call (888) 203-2358 to confirm availability.
