11MP012-6CA1 Timing Pulley, 11 Teeth, MXL Pitch, 1/8 in Bore


Price:
$ 10.79

Description

11MP012-6CA1 Timing Pulley, 11 Teeth, MXL Pitch, 1/8 in Bore

The 11MP012-6CA1 is a 11-tooth MXL (0.080 in trapezoidal) timing pulley with a 1/8 in finished bore, machined from aluminum with a clear anodized finish, built for 0.125 in wide belts. Machined from solid stock, never sintered or powdered metal.

$50 minimum order on drive components. Mix and match any pulleys, bushings, sheaves, sprockets, and accessories in your cart to reach the $50 minimum. Questions? Call (888) 203-2358.

Specifications

Type 6C pulley construction dimension diagram

Dimension key for this construction type. Values for this part number are in the table below.

Specification Value
Part Number 11MP012-6CA1
Teeth 11
Pitch MXL (0.080 in trapezoidal)
For Belt Width 0.125 in
Pitch Diameter 0.2801 in
Outside Diameter 0.2601 in
Flange Diameter 0.45 in
Bore 1/8 in finished bore
Face Width 0.201 in
Overall Length 0.438 in
Hub Diameter 0.45 in
Construction Standard Hub Serves as 2nd Flange
Set Screws 1 x 4-40
Flange Material Aluminum
Material Aluminum (no sintered or powdered metal)
Finish Clear Anodized
Weight 0.005 lb
Country of Origin India

Applications

  • Instrumentation, office equipment, and precision positioning drives
  • 3D printers and desktop CNC equipment
  • Robotics, medical devices, and packaging machinery

Belt Compatibility

The 11MP012-6CA1 runs MXL (0.080 in trapezoidal) belts in 0.125 in width. The pitch is standardized, so belt and pulley brands can be mixed.

Cross Reference

The 11MP012-6CA1 interchanges with these equivalent part numbers, per published manufacturer interchange data:

Manufacturer Equivalent Part Number
Gates® PB11MXL012
Mitsuboshi 11-MP012-6CA1
Stock Drive Products (SDP/SI) A 6N16-011DF1204
Neuman 11MP-012-1/8-6FCA
W.M. Berg TP7A2W2-11
McMaster-Carr 1375K12
Powerdrive 11MP012-6CA1

Always verify dimensions and bore size before substituting part numbers across manufacturers.

Buying in bulk? Save on volume.

Multi-unit and OEM quantities qualify for volume discounts. Call or email for a quantity quote.

Frequently Asked Questions

What belts fit the 11MP012-6CA1 pulley?

MXL (0.080 in trapezoidal) timing belts in 0.125 in width from any manufacturer. The pitch is standardized, so belt and pulley brands can be mixed.

Does the 11MP012-6CA1 replace the Gates PB11MXL012?

Yes. Published interchange data crosses the 11MP012-6CA1 directly to the Gates PB11MXL012, as well as Mitsuboshi 11-MP012-6CA1, Stock Drive Products A 6N16-011DF1204, Neuman 11MP-012-1/8-6FCA. Verify dimensions and bore before ordering.

Does the 11MP012-6CA1 ship from Houston?

Yes. Stock items ship same day from our Houston, Texas warehouse. Call (888) 203-2358 to confirm availability.

Need a quote on 11MP012-6CA1?

Houston warehouse, same-day shipping on stock items.

Call (888) 203-2358

All third-party part numbers and trademarks referenced are the property of their respective owners. References are for compatibility identification only and do not imply affiliation or endorsement.
