12C200M V-Belt Sheave, 12 Grooves, C Section, 20.4 in OD, M Bushing


Price:
$ 1,815

Description

Representative image shown. Actual product appearance varies by size, bore, and configuration. Refer to the specifications table for exact dimensions of this part number.

12C200M V-Belt Sheave, 12 Grooves, C Section, 20.4 in OD, M Bushing

The 12C200M is a 12-groove C section classical section V-belt sheave with a 20.4 in outside diameter, fully machined from cast iron and statically balanced. It mounts with an industry-standard M QD® style bushing, sold separately, sized to your shaft. It runs C section V-belts.

Specifications

Specification Value
Part Number 12C200M
Belt Section C
Grooves 12
Outside Diameter 20.4 in
Face Width 12.25 in
Bushing M series, QD® style (not included)
Material Cast Iron, fully machined, statically balanced
Weight 245 lb
Country of Origin China

Applications

  • Classical section V-belt drives on fans, pumps, and compressors
  • HVAC and refrigeration equipment
  • General industrial machinery with A, B, or C section belts
  • Replacing worn sheaves on existing drives

Cross Reference

The 12C200M interchanges with these equivalent part numbers, per published manufacturer interchange data:

Manufacturer Equivalent Part Number
Dodge® D12C200
Martin 12 C 200 M
Gates® QD12C20.0
TB Woods® 20012C
Regal Rexnord (Browning®) 12C200M
Carlisle 12-C-200-M
Maurey 12C20.0
Jason Industrial 12C200M
Goodyear 20.0-12C-M

Always verify dimensions and bore size before substituting part numbers across manufacturers.

Buying in bulk? Save on volume.

Multi-unit and OEM quantities qualify for volume discounts. Call or email for a quantity quote.

Frequently Asked Questions

What belts run on the 12C200M?

C section V-belts. These sections are standardized, so any manufacturer's belts of the correct section and length will run in the grooves.

Does the 12C200M replace the Dodge D12C200 sheave?

Yes. Published interchange data crosses the 12C200M directly to the Dodge D12C200, as well as Martin 12 C 200 M, Gates QD12C20.0, TB Woods 20012C. Verify groove count, diameter, and bore or bushing before ordering.

What bushing does the 12C200M use?

A M series QD style bushing, sold separately. M is an industry-standard bushing size, so any manufacturer's standard M bushing fits. Order the bushing bore that matches your shaft diameter.

Does the 12C200M ship from Houston?

Yes. Stock items ship same day from our Houston, Texas warehouse. Call (888) 203-2358 to confirm availability.

Need a quote on 12C200M?

Houston warehouse, same-day shipping on stock items.

Call (888) 203-2358

QD® is a registered trademark of TB Woods/Regal Rexnord. All third-party part numbers and trademarks referenced, including Dodge®, Gates®, Martin, TB Woods®, Browning®, and others shown in the cross reference table, are the property of their respective owners. References are for compatibility identification only and do not imply affiliation or endorsement.
