Description
16MP025MDFP4 Timing Pulley, 16 Teeth, MXL Pitch
The 16MP025MDFP4 is a 16-tooth MXL (0.080 in trapezoidal) timing pulley with a 4 mm Bore, machined from polycarbonate, built for 0.25 in wide belts. Machined from solid stock, never sintered or powdered metal.
$50 minimum order on drive components. Mix and match any pulleys, bushings, sheaves, sprockets, and accessories in your cart to reach the $50 minimum. Questions? Call (888) 203-2358.
Specifications
| Specification | Value |
|---|---|
| Part Number | 16MP025MDFP4 |
| Teeth | 16 |
| Pitch | MXL (0.080 in trapezoidal) |
| For Belt Width | 0.25 in |
| Pitch Diameter | 0.4074 in |
| Outside Diameter | 0.3874 in |
| Flange Diameter | 0.58 in |
| Bore | 4 mm Bore |
| Face Width | 0.433 in |
| Overall Length | 0.6875 in |
| Hub Diameter | 0.4375 in |
| Flange Material | Polycarbonate |
| Material | Polycarbonate (no sintered or powdered metal) |
| Weight | 0.005 lb |
| Country of Origin | United States. ISO 9001:2015 certified manufacturing. |
Applications
- Instrumentation, office equipment, and precision positioning drives
- 3D printers and desktop CNC equipment
- Robotics, medical devices, and packaging machinery
Belt Compatibility
The 16MP025MDFP4 runs MXL (0.080 in trapezoidal) belts in 0.25 in width. The pitch is standardized, so belt and pulley brands can be mixed.
Cross Reference
The 16MP025MDFP4 interchanges with these equivalent part numbers, per published manufacturer interchange data:
| Manufacturer | Equivalent Part Number |
|---|---|
| Stock Drive Products (SDP/SI) | A 6M16M016DF6004 |
| York | 16MXL025M-LDF |
| McMaster-Carr | 7717N22 |
| Powerdrive | 16MP025MDFP4 |
Always verify dimensions and bore size before substituting part numbers across manufacturers.
Buying in bulk? Save on volume.
Multi-unit and OEM quantities qualify for volume discounts. Call or email for a quantity quote.
Frequently Asked Questions
What belts fit the 16MP025MDFP4 pulley?
MXL (0.080 in trapezoidal) timing belts in 0.25 in width from any manufacturer. The pitch is standardized, so belt and pulley brands can be mixed.
Does the 16MP025MDFP4 replace the Stock Drive Products A 6M16M016DF6004?
Yes. Published interchange data crosses the 16MP025MDFP4 directly to the Stock Drive Products A 6M16M016DF6004, as well as York 16MXL025M-LDF, McMaster-Carr 7717N22, Powerdrive 16MP025MDFP4. Verify dimensions and bore before ordering.
Does the 16MP025MDFP4 ship from Houston?
Yes. Stock items ship same day from our Houston, Texas warehouse. Call (888) 203-2358 to confirm availability.
