20H100-6FS7 Timing Pulley, 2 Teeth, H Pitch


Price:
$ 63.56

Description

20H100-6FS7 Timing Pulley, 2 Teeth, H Pitch

The 20H100-6FS7 is a 2-tooth H (0.500 in trapezoidal) timing pulley with a 5/8 in minimum plain bore, machined from ductile iron with a black oxide finish, built for 1 in wide belts. Machined from solid stock, never sintered or powdered metal.

Specifications

Type 6FNOKEY pulley construction dimension diagram

Dimension key for this construction type. Values for this part number are in the table below.

Specification Value
Part Number 20H100-6FS7
Teeth 2
Pitch H (0.500 in trapezoidal)
For Belt Width 1 in
Pitch Diameter 3.1831 in
Outside Diameter 3.1291 in
Flange Diameter 3.42 in
Bore 5/8 in minimum plain bore
Face Width 1.312 in
Overall Length 2.125 in
Hub Diameter 2.5 in
Construction Standard Hub
Flange Material Steel
Material Ductile Iron (no sintered or powdered metal)
Finish Black Oxide
Weight 3.486 lb
Country of Origin United States. ISO 9001:2015 certified manufacturing.

Applications

  • Instrumentation, office equipment, and precision positioning drives
  • 3D printers and desktop CNC equipment
  • Robotics, medical devices, and packaging machinery

Belt Compatibility

The 20H100-6FS7 runs H (0.500 in trapezoidal) belts in 1 in width. The pitch is standardized, so belt and pulley brands can be mixed.

Cross Reference

The 20H100-6FS7 interchanges with these equivalent part numbers, per published manufacturer interchange data:

Manufacturer Equivalent Part Number
Dodge® 20H100-MPB
Martin 20H100
TB Woods® 20H100MPB
Regal Rexnord (Browning®) 20HB100
Mitsuboshi 20H100-6FS7
McMaster-Carr 6495K46
Grainger 809V58
Powerdrive 20H100-6FS7
Continental (ContiTech) 20H100-5/8

Always verify dimensions and bore size before substituting part numbers across manufacturers.
