20XHQ200 Timing Pulley, 2 Teeth, XH Pitch


Price:
$ 337.48

Description

20XHQ200 Timing Pulley, 2 Teeth, XH Pitch

The 20XHQ200 is a 2-tooth XH (0.875 in trapezoidal) timing pulley. It mounts with an industry-standard bushing, sold separately, machined from ductile iron, built for 2 in wide belts. Machined from solid stock, never sintered or powdered metal.

Specifications

Type 10 pulley construction dimension diagram

Dimension key for this construction type. Values for this part number are in the table below.

Specification Value
Part Number 20XHQ200
Teeth 2
Pitch XH (0.875 in trapezoidal)
For Belt Width 2 in
Pitch Diameter 5.5704 in
Outside Diameter 5.4604 in
Flange Diameter 6.125 in
Bore Accepts Q1 bushing (not included)
Face Width 2.563 in
Overall Length 2.781 in
Construction Split Taper Hub
Flange Material Steel
Material Ductile Iron (no sintered or powdered metal)
Weight 8.807 lb
Country of Origin United States. ISO 9001:2015 certified manufacturing.

Applications

  • Instrumentation, office equipment, and precision positioning drives
  • 3D printers and desktop CNC equipment
  • Robotics, medical devices, and packaging machinery

Belt Compatibility

The 20XHQ200 runs XH (0.875 in trapezoidal) belts in 2 in width. The pitch is standardized, so belt and pulley brands can be mixed.

Cross Reference

The 20XHQ200 interchanges with these equivalent part numbers, per published manufacturer interchange data:

Manufacturer Equivalent Part Number
Regal Rexnord (Browning®) 20XHQ200
Powerdrive 20XHQ200

Always verify dimensions and bore size before substituting part numbers across manufacturers.

Buying in bulk? Save on volume.

Multi-unit and OEM quantities qualify for volume discounts. Call or email for a quantity quote.

Frequently Asked Questions

What belts fit the 20XHQ200 pulley?

XH (0.875 in trapezoidal) timing belts in 2 in width from any manufacturer. The pitch is standardized, so belt and pulley brands can be mixed.

Does the 20XHQ200 replace the Regal Rexnord 20XHQ200?

Yes. Published interchange data crosses the 20XHQ200 directly to the Regal Rexnord 20XHQ200, as well as Powerdrive 20XHQ200. Verify dimensions and bore before ordering.

Does the 20XHQ200 ship from Houston?

Yes. Stock items ship same day from our Houston, Texas warehouse. Call (888) 203-2358 to confirm availability.

Need a quote on 20XHQ200?

Houston warehouse, same-day shipping on stock items.

Call (888) 203-2358

All third-party part numbers and trademarks referenced are the property of their respective owners. References are for compatibility identification only and do not imply affiliation or endorsement.
