224-8MX12-2517 Powerhouse® MX Timing Pulley, 224 Teeth, 8MX Pitch


Price:
$ 535.86

Description

Representative image shown. Actual product appearance varies by size, bore, and configuration. Refer to the specifications table for exact dimensions of this part number.

224-8MX12-2517 Powerhouse® MX Timing Pulley, 224 Teeth, 8MX Pitch

The 224-8MX12-2517 is a 224-tooth 8 mm MX high torque timing pulley. It mounts with an industry-standard bushing, sold separately, machined from ductile iron with a black oxide finish, built for 12mm wide belts. Machined from solid stock, never sintered or powdered metal. Powerhouse® MX pulleys run on the same high torque drives as Gates Poly Chain® GT® Carbon™ and Continental Synchrochain Carbon belts.

Specifications

Type C3 pulley construction dimension diagram

Dimension key for this construction type. Values for this part number are in the table below.

Specification Value
Part Number 224-8MX12-2517
Teeth 224
Pitch 8 mm MX high torque
For Belt Width 12mm
Pitch Diameter 22.4571 in
Outside Diameter 22.3941 in
Bore Accepts 2517 bushing (not included)
Face Width 0.85 in
Overall Length 1.75 in
Construction Taper Lock Hub
Material Ductile Iron (no sintered or powdered metal)
Finish Black Oxide
Weight 37 lb
Country of Origin United States. ISO 9001:2015 certified manufacturing.

Applications

  • High torque, low speed drives replacing roller chain
  • Air cooled heat exchanger (ACHE) fan drives
  • Oil and gas pumping equipment
  • Material handling and conveyor drives
  • Weight-sensitive drives (webbed, lightened construction)

Belt Compatibility

The 224-8MX12-2517 runs 8 mm MX high torque belts in 12mm width. The pitch is standardized, so belt and pulley brands can be mixed.

Cross Reference

The 224-8MX12-2517 interchanges with these equivalent part numbers, per published manufacturer interchange data:

Manufacturer Equivalent Part Number
Dodge® 8MX-224S-12-2517
Martin 8MX224S12-2517
Gates® 8MX-224S-12
TB Woods® 8MPC224S12
Regal Rexnord (Browning®) B8MCS-224-12
Mitsuboshi 224-8MX12-2517
Grainger 809RJ1
Powerdrive 224-8MX12-2517
Continental (ContiTech) 224G-8M-12-2517

Always verify dimensions and bore size before substituting part numbers across manufacturers.

Buying in bulk? Save on volume.

Multi-unit and OEM quantities qualify for volume discounts. Call or email for a quantity quote.

Frequently Asked Questions

What belts fit the 224-8MX12-2517 pulley?

8 mm MX high torque timing belts in 12mm width from any manufacturer. The pitch is standardized, so belt and pulley brands can be mixed.

Does the 224-8MX12-2517 replace the Dodge 8MX-224S-12-2517?

Yes. Published interchange data crosses the 224-8MX12-2517 directly to the Dodge 8MX-224S-12-2517, as well as Martin 8MX224S12-2517, Gates 8MX-224S-12, TB Woods 8MPC224S12. Verify dimensions and bore before ordering.

Does the 224-8MX12-2517 ship from Houston?

Yes. Stock items ship same day from our Houston, Texas warehouse. Call (888) 203-2358 to confirm availability.

Need a quote on 224-8MX12-2517?

Houston warehouse, same-day shipping on stock items.

Call (888) 203-2358

Powerhouse® is a registered trademark of its owner. Poly Chain®, GT®, and Carbon™ are trademarks of Gates Corporation. Synchrochain is a trademark of Continental. All third-party part numbers and trademarks referenced are the property of their respective owners. References are for compatibility identification only and do not imply affiliation or endorsement.
