Description
22L075-6FA6 Timing Pulley, 22 Teeth, L Pitch, 1/2 in Bore
The 22L075-6FA6 is a 22-tooth L (0.375 in trapezoidal) timing pulley with a 1/2 in finished bore, machined from aluminum with a clear anodized finish, built for 0.75 in wide belts. Machined from solid stock, never sintered or powdered metal.
Specifications

Dimension key for this construction type. Values for this part number are in the table below.
| Specification | Value |
|---|---|
| Part Number | 22L075-6FA6 |
| Teeth | 22 |
| Pitch | L (0.375 in trapezoidal) |
| For Belt Width | 0.75 in |
| Pitch Diameter | 2.6261 in |
| Outside Diameter | 2.5961 in |
| Flange Diameter | 2.875 in |
| Bore | 1/2 in finished bore |
| Face Width | 1 in |
| Overall Length | 1.5 in |
| Hub Diameter | 2.125 in |
| Construction | Standard Hub |
| Set Screws | 2 x 1/4-20 |
| Flange Material | Aluminum |
| Material | Aluminum (no sintered or powdered metal) |
| Finish | Clear Anodized |
| Weight | 0.7 lb |
| Country of Origin | United States. ISO 9001:2015 certified manufacturing. |
Applications
- Instrumentation, office equipment, and precision positioning drives
- 3D printers and desktop CNC equipment
- Robotics, medical devices, and packaging machinery
Belt Compatibility
The 22L075-6FA6 runs L (0.375 in trapezoidal) belts in 0.75 in width. The pitch is standardized, so belt and pulley brands can be mixed.
Cross Reference
The 22L075-6FA6 interchanges with these equivalent part numbers, per published manufacturer interchange data:
| Manufacturer | Equivalent Part Number |
|---|---|
| Mitsuboshi | 22L075-6FA6 |
| McMaster-Carr | 1304N23 |
| Powerdrive | 22L075-6FA6 |
Always verify dimensions and bore size before substituting part numbers across manufacturers.
Buying in bulk? Save on volume.
Multi-unit and OEM quantities qualify for volume discounts. Call or email for a quantity quote.
Frequently Asked Questions
What belts fit the 22L075-6FA6 pulley?
L (0.375 in trapezoidal) timing belts in 0.75 in width from any manufacturer. The pitch is standardized, so belt and pulley brands can be mixed.
Does the 22L075-6FA6 replace the Mitsuboshi 22L075-6FA6?
Yes. Published interchange data crosses the 22L075-6FA6 directly to the Mitsuboshi 22L075-6FA6, as well as McMaster-Carr 1304N23, Powerdrive 22L075-6FA6. Verify dimensions and bore before ordering.
Does the 22L075-6FA6 ship from Houston?
Yes. Stock items ship same day from our Houston, Texas warehouse. Call (888) 203-2358 to confirm availability.
