22XH400-6FS10 Timing Pulley, 22 Teeth, XH Pitch


Price:
$ 376.71

Description

22XH400-6FS10 Timing Pulley, 22 Teeth, XH Pitch

The 22XH400-6FS10 is a 22-tooth XH (0.875 in trapezoidal) timing pulley with a 1 in minimum plain bore, machined from steel with a black oxide finish, built for 4 in wide belts. Machined from solid stock, never sintered or powdered metal.

Specifications

Type 6FNOKEY pulley construction dimension diagram

Dimension key for this construction type. Values for this part number are in the table below.

Specification Value
Part Number 22XH400-6FS10
Teeth 22
Pitch XH (0.875 in trapezoidal)
For Belt Width 4 in
Pitch Diameter 6.1275 in
Outside Diameter 6.0175 in
Flange Diameter 6.688 in
Bore 1 in minimum plain bore
Face Width 4.688 in
Overall Length 5.938 in
Hub Diameter 4.75 in
Construction Standard Hub
Flange Material Steel
Material Steel (no sintered or powdered metal)
Finish Black Oxide
Weight 40.8 lb
Country of Origin United States. ISO 9001:2015 certified manufacturing.

Applications

  • Instrumentation, office equipment, and precision positioning drives
  • 3D printers and desktop CNC equipment
  • Robotics, medical devices, and packaging machinery

Belt Compatibility

The 22XH400-6FS10 runs XH (0.875 in trapezoidal) belts in 4 in width. The pitch is standardized, so belt and pulley brands can be mixed.

Cross Reference

The 22XH400-6FS10 interchanges with these equivalent part numbers, per published manufacturer interchange data:

Manufacturer Equivalent Part Number
Martin 22XH400
TB Woods® 22XH400MPB
Regal Rexnord (Browning®) 22XHB400
Powerdrive 22XH400-6FS10

Always verify dimensions and bore size before substituting part numbers across manufacturers.

Buying in bulk? Save on volume.

Multi-unit and OEM quantities qualify for volume discounts. Call or email for a quantity quote.

Frequently Asked Questions

What belts fit the 22XH400-6FS10 pulley?

XH (0.875 in trapezoidal) timing belts in 4 in width from any manufacturer. The pitch is standardized, so belt and pulley brands can be mixed.

Does the 22XH400-6FS10 replace the Martin 22XH400?

Yes. Published interchange data crosses the 22XH400-6FS10 directly to the Martin 22XH400, as well as TB Woods 22XH400MPB, Regal Rexnord 22XHB400, Powerdrive 22XH400-6FS10. Verify dimensions and bore before ordering.

Does the 22XH400-6FS10 ship from Houston?

Yes. Stock items ship same day from our Houston, Texas warehouse. Call (888) 203-2358 to confirm availability.

Need a quote on 22XH400-6FS10?

Houston warehouse, same-day shipping on stock items.

Call (888) 203-2358

All third-party part numbers and trademarks referenced are the property of their respective owners. References are for compatibility identification only and do not imply affiliation or endorsement.
