2AK32x1-1/8 Light Duty V-Belt Sheave, 2 Grooves, 3.25 in OD, 1-1/8 in Bore
The 2AK32x1-1/8 is a 2-groove light duty V-belt sheave with a 3.25 in outside diameter, fully machined from cast iron and statically balanced, supplied with a 1-1/8 in finished bore. It runs 3L, 4L, and A section V-belts.
$50 minimum order on drive components. Mix and match any pulleys, bushings, sheaves, sprockets, and accessories in your cart to reach the $50 minimum. Questions? Call (888) 203-2358.
Specifications
| Specification | Value |
|---|---|
| Part Number | 2AK32x1-1/8 |
| Belt Section | AK |
| Grooves | 2 |
| Outside Diameter | 3.25 in |
| Face Width | 1.375 in |
| Bore | 1-1/8 in finished bore |
| Keyway / Set Screw | 1 x 5/16-18 UNC |
| Material | Cast Iron, fully machined, statically balanced |
| Weight | 2 lb |
| Country of Origin | China |
Applications
- Fractional horsepower motor drives
- Furnace blowers, attic fans, and air handlers
- Power tools, lawn equipment, and light machinery
- Direct replacement for worn FHP sheaves
Cross Reference
The 2AK32x1-1/8 interchanges with these equivalent part numbers, per published manufacturer interchange data:
| Manufacturer | Equivalent Part Number |
|---|---|
| Dodge® | 2AK32 X 1-1/8 |
| Martin | 2AK32 1 1/8 |
| Gates® | 2AK32 1.1/8 |
| TB Woods® | 2AK32118 |
| Regal Rexnord (Browning®) | 2AK32X 1 1/8 |
| Carlisle | 2-AK-32-1 1/8 |
| Masterdrive | 2AK32-1-1/8 |
| Maurey | 2AK32 X 1-1/8 |
| Jason Industrial | 2AK32-1-1/8 |
| Optibelt | 2AK32-1 1/8 |
Always verify dimensions and bore size before substituting part numbers across manufacturers.
Buying in bulk? Save on volume.
Multi-unit and OEM quantities qualify for volume discounts. Call or email for a quantity quote.
Frequently Asked Questions
What belts run on the 2AK32x1-1/8?
3L, 4L, and A section V-belts. These sections are standardized, so any manufacturer's belts of the correct section and length will run in the grooves.
Does the 2AK32x1-1/8 replace the Dodge 2AK32 X 1-1/8 sheave?
Yes. Published interchange data crosses the 2AK32x1-1/8 directly to the Dodge 2AK32 X 1-1/8, as well as Martin 2AK32 1 1/8, Gates 2AK32 1.1/8, TB Woods 2AK32118. Verify groove count, diameter, and bore or bushing before ordering.
Does the 2AK32x1-1/8 ship from Houston?
Yes. Stock items ship same day from our Houston, Texas warehouse. Call (888) 203-2358 to confirm availability.
