2AK59x1 Light Duty V-Belt Sheave, 2 Grooves, 5.75 in OD, 1 in Bore


Price:
$ 62.90

Description

2AK59x1 Light Duty V-Belt Sheave, 2 Grooves, 5.75 in OD, 1 in Bore

The 2AK59x1 is a 2-groove light duty V-belt sheave with a 5.75 in outside diameter, fully machined from cast iron and statically balanced, supplied with a 1 in finished bore. It runs 3L, 4L, and A section V-belts.

Specifications

Specification Value
Part Number 2AK59x1
Belt Section AK
Grooves 2
Outside Diameter 5.75 in
Face Width 1.375 in
Bore 1 in finished bore
Keyway / Set Screw 1 x 5/16-18 UNC
Material Cast Iron, fully machined, statically balanced
Weight 4.2 lb
Country of Origin China

Applications

  • Fractional horsepower motor drives
  • Furnace blowers, attic fans, and air handlers
  • Power tools, lawn equipment, and light machinery
  • Direct replacement for worn FHP sheaves

Cross Reference

The 2AK59x1 interchanges with these equivalent part numbers, per published manufacturer interchange data:

Manufacturer Equivalent Part Number
Dodge® 2AK59 X 1
Martin 2AK59 1
Gates® 2AK59 1
TB Woods® 2AK591
Regal Rexnord (Browning®) 2AK59x1
Carlisle 2-AK-59-1
Masterdrive 2AK59-1
Maurey 2AK59 X 1
Jason Industrial 2AK59-1
Optibelt 2AK59-1

Always verify dimensions and bore size before substituting part numbers across manufacturers.

Buying in bulk? Save on volume.

Multi-unit and OEM quantities qualify for volume discounts. Call or email for a quantity quote.

Frequently Asked Questions

What belts run on the 2AK59x1?

3L, 4L, and A section V-belts. These sections are standardized, so any manufacturer's belts of the correct section and length will run in the grooves.

Does the 2AK59x1 replace the Dodge 2AK59 X 1 sheave?

Yes. Published interchange data crosses the 2AK59x1 directly to the Dodge 2AK59 X 1, as well as Martin 2AK59 1, Gates 2AK59 1, TB Woods 2AK591. Verify groove count, diameter, and bore or bushing before ordering.

Does the 2AK59x1 ship from Houston?

Yes. Stock items ship same day from our Houston, Texas warehouse. Call (888) 203-2358 to confirm availability.

Need a quote on 2AK59x1?

Houston warehouse, same-day shipping on stock items.

Call (888) 203-2358

QD® is a registered trademark of TB Woods/Regal Rexnord. All third-party part numbers and trademarks referenced, including Dodge®, Gates®, Martin, TB Woods®, Browning®, and others shown in the cross reference table, are the property of their respective owners. References are for compatibility identification only and do not imply affiliation or endorsement.
