2BK45H Light Duty V-Belt Sheave, 2 Grooves, 4.25 in OD, H Bushing


Price:
$ 43.71

Description

2BK45H Light Duty V-Belt Sheave, 2 Grooves, 4.25 in OD, H Bushing

The 2BK45H is a 2-groove light duty V-belt sheave with a 4.25 in outside diameter, fully machined from cast iron and statically balanced. It mounts with an industry-standard H QD® style bushing, sold separately, sized to your shaft. It runs 4L, 5L, A, and B section V-belts.

$50 minimum order on drive components. Mix and match any pulleys, bushings, sheaves, sprockets, and accessories in your cart to reach the $50 minimum. Questions? Call (888) 203-2358.

Specifications

Specification Value
Part Number 2BK45H
Belt Section BK
Grooves 2
Outside Diameter 4.25 in
Pitch Diameter (A / B belts) 3.5 in / 3.9 in
Face Width 1.75 in
Bushing H series, QD® style (not included)
Material Cast Iron, fully machined, statically balanced
Weight 3 lb
Country of Origin China

Applications

  • Fractional horsepower motor drives
  • Furnace blowers, attic fans, and air handlers
  • Power tools, lawn equipment, and light machinery
  • Direct replacement for worn FHP sheaves

Cross Reference

The 2BK45H interchanges with these equivalent part numbers, per published manufacturer interchange data:

Manufacturer Equivalent Part Number
Dodge® 2BK45QT
Martin 2BK45-H
Gates® 2BK45QT
TB Woods® 2BK45
Regal Rexnord (Browning®) 2BK45H
Carlisle 2-BK-45-H
Masterdrive 2BK45H
Maurey 2BK45H
Jason Industrial 2BK45H
Optibelt 2BK45H

Always verify dimensions and bore size before substituting part numbers across manufacturers.

Buying in bulk? Save on volume.

Multi-unit and OEM quantities qualify for volume discounts. Call or email for a quantity quote.

Frequently Asked Questions

What belts run on the 2BK45H?

4L, 5L, A, and B section V-belts. These sections are standardized, so any manufacturer's belts of the correct section and length will run in the grooves.

Does the 2BK45H replace the Dodge 2BK45QT sheave?

Yes. Published interchange data crosses the 2BK45H directly to the Dodge 2BK45QT, as well as Martin 2BK45-H, Gates 2BK45QT, TB Woods 2BK45. Verify groove count, diameter, and bore or bushing before ordering.

What bushing does the 2BK45H use?

A H series QD style bushing, sold separately. H is an industry-standard bushing size, so any manufacturer's standard H bushing fits. Order the bushing bore that matches your shaft diameter.

Why does the 2BK45H list two pitch diameters?

Combination sheaves run more than one belt section, and each section rides at a different depth in the groove. The 2BK45H has a 3.5 in pitch diameter with A or 4L belts and 3.9 in with B or 5L belts.

Does the 2BK45H ship from Houston?

Yes. Stock items ship same day from our Houston, Texas warehouse. Call (888) 203-2358 to confirm availability.
