2VP56x5/8 Adjustable Pitch Sheave, 2 Grooves, 5.35 in OD


Price:
$ 100.37

Description

2VP56x5/8 Adjustable Pitch Sheave, 2 Grooves, 5.35 in OD

The 2VP56x5/8 is a 2-groove adjustable pitch sheave with a 5.35 in outside diameter, fully machined from cast iron and statically balanced, supplied with a 5/8 in Bore.

Specifications

Specification Value
Part Number 2VP56x5/8
Belt Section VP
Grooves 2
Outside Diameter 5.35 in
Bore 5/8 in Bore
Material Cast Iron, fully machined, statically balanced
Weight 7.8 lb
Country of Origin China

Applications

  • Tuning driven speed on fans and blowers without changing components
  • HVAC balancing and airflow adjustment
  • Fractional horsepower drives needing field-adjustable ratios

Cross Reference

The 2VP56x5/8 interchanges with these equivalent part numbers, per published manufacturer interchange data:

Manufacturer Equivalent Part Number
Martin 2VP56 5/8
Gates® 2VP56.5/8
TB Woods® 2VP5658
Regal Rexnord (Browning®) 2VP56x5/8
Carlisle 2VP56-5/8
Masterdrive 2VP56-5/8
Maurey 2VP56 X 5/8
Jason Industrial 2VP56-5/8
Optibelt 2VP56-5/8
Goodyear 2VP56-5/8

Always verify dimensions and bore size before substituting part numbers across manufacturers.

Buying in bulk? Save on volume.

Multi-unit and OEM quantities qualify for volume discounts. Call or email for a quantity quote.

Frequently Asked Questions

Does the 2VP56x5/8 replace the Martin 2VP56 5/8 sheave?

Yes. Published interchange data crosses the 2VP56x5/8 directly to the Martin 2VP56 5/8, as well as Gates 2VP56.5/8, TB Woods 2VP5658, Regal Rexnord (Browning) 2VP56x5/8. Verify groove count, diameter, and bore or bushing before ordering.

How does an adjustable pitch sheave like the 2VP56x5/8 work?

The sheave flanks thread apart or together, changing the effective pitch diameter and therefore the driven speed. Adjust with the belt off, set both flanks evenly, and lock the set screw before running.

Does the 2VP56x5/8 ship from Houston?

Yes. Stock items ship same day from our Houston, Texas warehouse. Call (888) 203-2358 to confirm availability.

Need a quote on 2VP56x5/8?

Houston warehouse, same-day shipping on stock items.

Call (888) 203-2358

QD® is a registered trademark of TB Woods/Regal Rexnord. All third-party part numbers and trademarks referenced, including Dodge®, Gates®, Martin, TB Woods®, Browning®, and others shown in the cross reference table, are the property of their respective owners. References are for compatibility identification only and do not imply affiliation or endorsement.
