31AT10/60-0 Timing Pulley, 6 Teeth, AT10 Pitch


Price:
$ 143.33

Description

31AT10/60-0 Timing Pulley, 6 Teeth, AT10 Pitch

The 31AT10/60-0 is a 6-tooth AT10 (10 mm metric) timing pulley with a 16 mm minimum plain bore, machined from aluminum, built for 16mm wide belts. Machined from solid stock, never sintered or powdered metal.

Specifications

Type 6NOKEY pulley construction dimension diagram

Dimension key for this construction type. Values for this part number are in the table below.

Specification Value
Part Number 31AT10/60-0
Teeth 6
Pitch AT10 (10 mm metric)
For Belt Width 16mm
Pitch Diameter 7.5191 in
Outside Diameter 7.4435 in
Bore 16 mm minimum plain bore
Construction Standard Hub
Material Aluminum (no sintered or powdered metal)
Weight 4.299 lb
Country of Origin China

Applications

  • Instrumentation, office equipment, and precision positioning drives
  • 3D printers and desktop CNC equipment
  • Robotics, medical devices, and packaging machinery

Belt Compatibility

The 31AT10/60-0 runs AT10 (10 mm metric) belts in 16mm width. The pitch is standardized, so belt and pulley brands can be mixed.

Cross Reference

The 31AT10/60-0 interchanges with these equivalent part numbers, per published manufacturer interchange data:

Manufacturer Equivalent Part Number
Mitsuboshi 31AT10/60-0
Jason Industrial 31AT10/60-0
Optibelt 31AT10/60-0
Ametric 31AT10/60 0
McMaster-Carr 3709N56
Powerdrive 31AT10/60-0

Always verify dimensions and bore size before substituting part numbers across manufacturers.

Buying in bulk? Save on volume.

Multi-unit and OEM quantities qualify for volume discounts. Call or email for a quantity quote.

Frequently Asked Questions

What belts fit the 31AT10/60-0 pulley?

AT10 (10 mm metric) timing belts in 16mm width from any manufacturer. The pitch is standardized, so belt and pulley brands can be mixed.

Does the 31AT10/60-0 replace the Mitsuboshi 31AT10/60-0?

Yes. Published interchange data crosses the 31AT10/60-0 directly to the Mitsuboshi 31AT10/60-0, as well as Jason Industrial 31AT10/60-0, Optibelt 31AT10/60-0, Ametric 31AT10/60 0. Verify dimensions and bore before ordering.

Does the 31AT10/60-0 ship from Houston?

Yes. Stock items ship same day from our Houston, Texas warehouse. Call (888) 203-2358 to confirm availability.
