32HQ150 Timing Pulley, 32 Teeth, H Pitch


Price:
$ 140.77

Description

32HQ150 Timing Pulley, 32 Teeth, H Pitch

The 32HQ150 is a 32-tooth H (0.500 in trapezoidal) timing pulley. It mounts with an industry-standard bushing, sold separately, machined from ductile iron, built for 1.5 in wide belts. Machined from solid stock, never sintered or powdered metal.

Specifications

Type 7 pulley construction dimension diagram

Dimension key for this construction type. Values for this part number are in the table below.

Specification Value
Part Number 32HQ150
Teeth 32
Pitch H (0.500 in trapezoidal)
For Belt Width 1.5 in
Pitch Diameter 5.093 in
Outside Diameter 5.039 in
Flange Diameter 5.313 in
Bore Accepts Q1 bushing (not included)
Face Width 1.75 in
Overall Length 2.781 in
Construction Split Taper Hub
Flange Material Steel
Material Ductile Iron (no sintered or powdered metal)
Weight 6.25 lb
Country of Origin United States. ISO 9001:2015 certified manufacturing.

Applications

  • Instrumentation, office equipment, and precision positioning drives
  • 3D printers and desktop CNC equipment
  • Robotics, medical devices, and packaging machinery

Belt Compatibility

The 32HQ150 runs H (0.500 in trapezoidal) belts in 1.5 in width. The pitch is standardized, so belt and pulley brands can be mixed.

Cross Reference

The 32HQ150 interchanges with these equivalent part numbers, per published manufacturer interchange data:

Manufacturer Equivalent Part Number
Regal Rexnord (Browning®) 32HQ150
Powerdrive 32HQ150

Always verify dimensions and bore size before substituting part numbers across manufacturers.

Buying in bulk? Save on volume.

Multi-unit and OEM quantities qualify for volume discounts. Call or email for a quantity quote.

Frequently Asked Questions

What belts fit the 32HQ150 pulley?

H (0.500 in trapezoidal) timing belts in 1.5 in width from any manufacturer. The pitch is standardized, so belt and pulley brands can be mixed.

Does the 32HQ150 replace the Regal Rexnord 32HQ150?

Yes. Published interchange data crosses the 32HQ150 directly to the Regal Rexnord 32HQ150, as well as Powerdrive 32HQ150. Verify dimensions and bore before ordering.

Does the 32HQ150 ship from Houston?

Yes. Stock items ship same day from our Houston, Texas warehouse. Call (888) 203-2358 to confirm availability.

Need a quote on 32HQ150?

Houston warehouse, same-day shipping on stock items.

Call (888) 203-2358

All third-party part numbers and trademarks referenced are the property of their respective owners. References are for compatibility identification only and do not imply affiliation or endorsement.
