32XHR400 Timing Pulley, 32 Teeth, XH Pitch


Price:
$ 598.74

Description

32XHR400 Timing Pulley, 32 Teeth, XH Pitch

The 32XHR400 is a 32-tooth XH (0.875 in trapezoidal) timing pulley. It mounts with an industry-standard bushing, sold separately, machined from cast iron, built for 4 in wide belts. Machined from solid stock, never sintered or powdered metal.

Specifications

Type 11 pulley construction dimension diagram

Dimension key for this construction type. Values for this part number are in the table below.

Specification Value
Part Number 32XHR400
Teeth 32
Pitch XH (0.875 in trapezoidal)
For Belt Width 4 in
Pitch Diameter 8.9127 in
Outside Diameter 8.8027 in
Flange Diameter 9.438 in
Bore Accepts R2 bushing (not included)
Face Width 4.688 in
Overall Length 5.156 in
Construction Split Taper Hub
Flange Material Steel
Material Cast Iron (no sintered or powdered metal)
Weight 51 lb
Country of Origin China

Applications

  • Instrumentation, office equipment, and precision positioning drives
  • 3D printers and desktop CNC equipment
  • Robotics, medical devices, and packaging machinery

Belt Compatibility

The 32XHR400 runs XH (0.875 in trapezoidal) belts in 4 in width. The pitch is standardized, so belt and pulley brands can be mixed.

Cross Reference

The 32XHR400 interchanges with these equivalent part numbers, per published manufacturer interchange data:

Manufacturer Equivalent Part Number
Regal Rexnord (Browning®) 32XHR400
Powerdrive 32XHR400

Always verify dimensions and bore size before substituting part numbers across manufacturers.

Buying in bulk? Save on volume.

Multi-unit and OEM quantities qualify for volume discounts. Call or email for a quantity quote.

Frequently Asked Questions

What belts fit the 32XHR400 pulley?

XH (0.875 in trapezoidal) timing belts in 4 in width from any manufacturer. The pitch is standardized, so belt and pulley brands can be mixed.

Does the 32XHR400 replace the Regal Rexnord 32XHR400?

Yes. Published interchange data crosses the 32XHR400 directly to the Regal Rexnord 32XHR400, as well as Powerdrive 32XHR400. Verify dimensions and bore before ordering.

Does the 32XHR400 ship from Houston?

Yes. Stock items ship same day from our Houston, Texas warehouse. Call (888) 203-2358 to confirm availability.

Need a quote on 32XHR400?

Houston warehouse, same-day shipping on stock items.

Call (888) 203-2358

All third-party part numbers and trademarks referenced are the property of their respective owners. References are for compatibility identification only and do not imply affiliation or endorsement.
