Description
36T5/60-0 Timing Pulley, 6 Teeth, T5 Pitch
The 36T5/60-0 is a 6-tooth T5 (5 mm metric) timing pulley with a 8 mm minimum plain bore, machined from aluminum, built for 25mm wide belts. Machined from solid stock, never sintered or powdered metal.
Specifications

Dimension key for this construction type. Values for this part number are in the table below.
| Specification | Value |
|---|---|
| Part Number | 36T5/60-0 |
| Teeth | 6 |
| Pitch | T5 (5 mm metric) |
| For Belt Width | 25mm |
| Pitch Diameter | 3.7596 in |
| Outside Diameter | 3.7233 in |
| Bore | 8 mm minimum plain bore |
| Construction | Standard Hub |
| Material | Aluminum (no sintered or powdered metal) |
| Weight | 1.433 lb |
| Country of Origin | India |
Applications
- Instrumentation, office equipment, and precision positioning drives
- 3D printers and desktop CNC equipment
- Robotics, medical devices, and packaging machinery
Belt Compatibility
The 36T5/60-0 runs T5 (5 mm metric) belts in 25mm width. The pitch is standardized, so belt and pulley brands can be mixed.
Cross Reference
The 36T5/60-0 interchanges with these equivalent part numbers, per published manufacturer interchange data:
| Manufacturer | Equivalent Part Number |
|---|---|
| Mitsuboshi | 36T5/60-2 |
| Jason Industrial | 36T5/60-0 |
| Optibelt | 36T5/60-0 |
| On Drives | 36T5/60-2 |
| Ametric | 36T5/60 0 |
| McMaster-Carr | 1428N78 |
| Powerdrive | 36T5/60-0 |
Always verify dimensions and bore size before substituting part numbers across manufacturers.
Buying in bulk? Save on volume.
Multi-unit and OEM quantities qualify for volume discounts. Call or email for a quantity quote.
Frequently Asked Questions
What belts fit the 36T5/60-0 pulley?
T5 (5 mm metric) timing belts in 25mm width from any manufacturer. The pitch is standardized, so belt and pulley brands can be mixed.
Does the 36T5/60-0 replace the Mitsuboshi 36T5/60-2?
Yes. Published interchange data crosses the 36T5/60-0 directly to the Mitsuboshi 36T5/60-2, as well as Jason Industrial 36T5/60-0, Optibelt 36T5/60-0, On Drives 36T5/60-2. Verify dimensions and bore before ordering.
Does the 36T5/60-0 ship from Houston?
Yes. Stock items ship same day from our Houston, Texas warehouse. Call (888) 203-2358 to confirm availability.
