36XL037-6A6 Timing Pulley, 36 Teeth, XL Pitch, 1/2 in Bore


Price:
$ 19.75

Description

36XL037-6A6 Timing Pulley, 36 Teeth, XL Pitch, 1/2 in Bore

The 36XL037-6A6 is a 36-tooth XL (0.200 in trapezoidal) timing pulley with a 1/2 in finished bore, machined from aluminum with a clear anodized finish, built for 0.375 in wide belts. Machined from solid stock, never sintered or powdered metal.

$50 minimum order on drive components. Mix and match any pulleys, bushings, sheaves, sprockets, and accessories in your cart to reach the $50 minimum. Questions? Call (888) 203-2358.

Specifications

Type 6 pulley construction dimension diagram

Dimension key for this construction type. Values for this part number are in the table below.

Specification Value
Part Number 36XL037-6A6
Teeth 36
Pitch XL (0.200 in trapezoidal)
For Belt Width 0.375 in
Pitch Diameter 2.2918 in
Outside Diameter 2.2718 in
Bore 1/2 in finished bore
Face Width 0.563 in
Overall Length 1 in
Hub Diameter 1.5 in
Construction Standard Hub
Set Screws 2 x 10-32
Material Aluminum (no sintered or powdered metal)
Finish Clear Anodized
Weight 0.3 lb
Country of Origin United States. ISO 9001:2015 certified manufacturing.

Applications

  • Instrumentation, office equipment, and precision positioning drives
  • 3D printers and desktop CNC equipment
  • Robotics, medical devices, and packaging machinery

Belt Compatibility

The 36XL037-6A6 runs XL (0.200 in trapezoidal) belts in 0.375 in width. The pitch is standardized, so belt and pulley brands can be mixed.

Cross Reference

The 36XL037-6A6 interchanges with these equivalent part numbers, per published manufacturer interchange data:

Manufacturer Equivalent Part Number
Mitsuboshi 36XL037-6A6
Stock Drive Products (SDP/SI) A 6A 3-36NF03716
Neuman 36XL037 X 1/2 6A
York 36XL037-2A 1/2
Powerdrive 36XL037-6A6

Always verify dimensions and bore size before substituting part numbers across manufacturers.

Buying in bulk? Save on volume.

Multi-unit and OEM quantities qualify for volume discounts. Call or email for a quantity quote.

Frequently Asked Questions

What belts fit the 36XL037-6A6 pulley?

XL (0.200 in trapezoidal) timing belts in 0.375 in width from any manufacturer. The pitch is standardized, so belt and pulley brands can be mixed.

Does the 36XL037-6A6 replace the Mitsuboshi 36XL037-6A6?

Yes. Published interchange data crosses the 36XL037-6A6 directly to the Mitsuboshi 36XL037-6A6, as well as Stock Drive Products A 6A 3-36NF03716, Neuman 36XL037 X 1/2 6A, York 36XL037-2A 1/2. Verify dimensions and bore before ordering.

Does the 36XL037-6A6 ship from Houston?

Yes. Stock items ship same day from our Houston, Texas warehouse. Call (888) 203-2358 to confirm availability.

Need a quote on 36XL037-6A6?

Houston warehouse, same-day shipping on stock items.

Call (888) 203-2358

All third-party part numbers and trademarks referenced are the property of their respective owners. References are for compatibility identification only and do not imply affiliation or endorsement.
