Description
40-5P09-6A4 Powerhouse® Timing Pulley, 4 Teeth, 5P Pitch, 5/16 in Bore
The 40-5P09-6A4 is a 4-tooth 5 mm Powerhouse® curvilinear timing pulley with a 5/16 in finished bore, machined from aluminum with a clear anodized finish, built for 9mm wide belts. Machined from solid stock, never sintered or powdered metal. The Powerhouse® modified curvilinear profile carries roughly twice the load of a standard curvilinear pulley of the same size.
$50 minimum order on drive components. Mix and match any pulleys, bushings, sheaves, sprockets, and accessories in your cart to reach the $50 minimum. Questions? Call (888) 203-2358.
Specifications

Dimension key for this construction type. Values for this part number are in the table below.
| Specification | Value |
|---|---|
| Part Number | 40-5P09-6A4 |
| Teeth | 4 |
| Pitch | 5 mm Powerhouse® curvilinear |
| For Belt Width | 9mm |
| Pitch Diameter | 2.5064 in |
| Outside Diameter | 2.4614 in |
| Bore | 5/16 in finished bore |
| Face Width | 0.546 in |
| Overall Length | 0.937 in |
| Hub Diameter | 1.5 in |
| Construction | Standard Hub |
| Set Screws | 2 x 8-32 |
| Material | Aluminum (no sintered or powdered metal) |
| Finish | Clear Anodized |
| Weight | 0.342 lb |
| Country of Origin | United States. ISO 9001:2015 certified manufacturing. |
Applications
- Higher load synchronous drives in compact spaces
- Industrial automation and conveyor drives
- Packaging and material handling equipment
Belt Compatibility
The 40-5P09-6A4 runs 5 mm Powerhouse® curvilinear belts in 9mm width. The pitch is standardized, so belt and pulley brands can be mixed.
Cross Reference
The 40-5P09-6A4 interchanges with these equivalent part numbers, per published manufacturer interchange data:
| Manufacturer | Equivalent Part Number |
|---|---|
| Gates® | P40-5MGT-09AL |
| Stock Drive Products (SDP/SI) | A 6A55-040NF0912 |
| Powerdrive | 40-5P09-6A4 |
Always verify dimensions and bore size before substituting part numbers across manufacturers.
Buying in bulk? Save on volume.
Multi-unit and OEM quantities qualify for volume discounts. Call or email for a quantity quote.
Frequently Asked Questions
What belts fit the 40-5P09-6A4 pulley?
5 mm Powerhouse® curvilinear timing belts in 9mm width from any manufacturer. The pitch is standardized, so belt and pulley brands can be mixed.
Does the 40-5P09-6A4 replace the Gates P40-5MGT-09AL?
Yes. Published interchange data crosses the 40-5P09-6A4 directly to the Gates P40-5MGT-09AL, as well as Stock Drive Products A 6A55-040NF0912, Powerdrive 40-5P09-6A4. Verify dimensions and bore before ordering.
Does the 40-5P09-6A4 ship from Houston?
Yes. Stock items ship same day from our Houston, Texas warehouse. Call (888) 203-2358 to confirm availability.
