40T10/60-0 Timing Pulley, 6 Teeth, T10 Pitch


Price:
$ 120

Description

40T10/60-0 Timing Pulley, 6 Teeth, T10 Pitch

The 40T10/60-0 is a 6-tooth T10 (10 mm metric) timing pulley with a 16 mm minimum plain bore, machined from aluminum, built for 25mm wide belts. Machined from solid stock, never sintered or powdered metal.

Specifications

Type 6NOKEY pulley construction dimension diagram

Dimension key for this construction type. Values for this part number are in the table below.

Specification Value
Part Number 40T10/60-0
Teeth 6
Pitch T10 (10 mm metric)
For Belt Width 25mm
Pitch Diameter 7.5191 in
Outside Diameter 7.442 in
Bore 16 mm minimum plain bore
Construction Standard Hub
Material Aluminum (no sintered or powdered metal)
Weight 4.75 lb
Country of Origin United States. ISO 9001:2015 certified manufacturing.

Applications

  • Instrumentation, office equipment, and precision positioning drives
  • 3D printers and desktop CNC equipment
  • Robotics, medical devices, and packaging machinery

Belt Compatibility

The 40T10/60-0 runs T10 (10 mm metric) belts in 25mm width. The pitch is standardized, so belt and pulley brands can be mixed.

Cross Reference

The 40T10/60-0 interchanges with these equivalent part numbers, per published manufacturer interchange data:

Manufacturer Equivalent Part Number
Mitsuboshi 40T10/60-0
Jason Industrial 40T10/60-0
Optibelt 40T10/60-0
On Drives 40T10/60-0
Ametric 40T10/60 0
Powerdrive 40T10/60-0

Always verify dimensions and bore size before substituting part numbers across manufacturers.

Buying in bulk? Save on volume.

Multi-unit and OEM quantities qualify for volume discounts. Call or email for a quantity quote.

Frequently Asked Questions

What belts fit the 40T10/60-0 pulley?

T10 (10 mm metric) timing belts in 25mm width from any manufacturer. The pitch is standardized, so belt and pulley brands can be mixed.

Does the 40T10/60-0 replace the Mitsuboshi 40T10/60-0?

Yes. Published interchange data crosses the 40T10/60-0 directly to the Mitsuboshi 40T10/60-0, as well as Jason Industrial 40T10/60-0, Optibelt 40T10/60-0, On Drives 40T10/60-0. Verify dimensions and bore before ordering.

Does the 40T10/60-0 ship from Houston?

Yes. Stock items ship same day from our Houston, Texas warehouse. Call (888) 203-2358 to confirm availability.

Need a quote on 40T10/60-0?

Houston warehouse, same-day shipping on stock items.

Call (888) 203-2358

All third-party part numbers and trademarks referenced are the property of their respective owners. References are for compatibility identification only and do not imply affiliation or endorsement.
