50-3P09-6A4 Powerhouse® Timing Pulley, 5 Teeth, 3P Pitch, 5/16 in Bore


Price:
$ 21.81

Description

50-3P09-6A4 Powerhouse® Timing Pulley, 5 Teeth, 3P Pitch, 5/16 in Bore

The 50-3P09-6A4 is a 5-tooth 3 mm Powerhouse® curvilinear timing pulley with a 5/16 in finished bore, machined from aluminum with a clear anodized finish, built for 9mm wide belts. Machined from solid stock, never sintered or powdered metal. The Powerhouse® modified curvilinear profile carries roughly twice the load of a standard curvilinear pulley of the same size.

$50 minimum order on drive components. Mix and match any pulleys, bushings, sheaves, sprockets, and accessories in your cart to reach the $50 minimum. Questions? Call (888) 203-2358.

Specifications

Type 6 pulley construction dimension diagram

Dimension key for this construction type. Values for this part number are in the table below.

Specification Value
Part Number 50-3P09-6A4
Teeth 5
Pitch 3 mm Powerhouse® curvilinear
For Belt Width 9mm
Pitch Diameter 1.8798 in
Outside Diameter 1.8498 in
Bore 5/16 in finished bore
Face Width 0.5 in
Overall Length 0.875 in
Hub Diameter 1.25 in
Construction Standard Hub
Set Screws 2 x 8-32
Material Aluminum (no sintered or powdered metal)
Finish Clear Anodized
Weight 0.1733 lb
Country of Origin India

Applications

  • Higher load synchronous drives in compact spaces
  • Industrial automation and conveyor drives
  • Packaging and material handling equipment

Belt Compatibility

The 50-3P09-6A4 runs 3 mm Powerhouse® curvilinear belts in 9mm width. The pitch is standardized, so belt and pulley brands can be mixed.

Cross Reference

The 50-3P09-6A4 interchanges with these equivalent part numbers, per published manufacturer interchange data:

Manufacturer Equivalent Part Number
Gates® 3MR-50S-09
Stock Drive Products (SDP/SI) A 6A53-050NF0910
Neuman 3MR-50S-09 6
York 50-3GT09-2A X 5/16
W.M. Berg TP3A3H9-50
McMaster-Carr 3764N143
Powerdrive 50-3P09-6A4

Always verify dimensions and bore size before substituting part numbers across manufacturers.

Buying in bulk? Save on volume.

Multi-unit and OEM quantities qualify for volume discounts. Call or email for a quantity quote.

Frequently Asked Questions

What belts fit the 50-3P09-6A4 pulley?

3 mm Powerhouse® curvilinear timing belts in 9mm width from any manufacturer. The pitch is standardized, so belt and pulley brands can be mixed.

Does the 50-3P09-6A4 replace the Gates 3MR-50S-09?

Yes. Published interchange data crosses the 50-3P09-6A4 directly to the Gates 3MR-50S-09, as well as Stock Drive Products A 6A53-050NF0910, Neuman 3MR-50S-09 6, York 50-3GT09-2A X 5/16. Verify dimensions and bore before ordering.

Does the 50-3P09-6A4 ship from Houston?

Yes. Stock items ship same day from our Houston, Texas warehouse. Call (888) 203-2358 to confirm availability.

Need a quote on 50-3P09-6A4?

Houston warehouse, same-day shipping on stock items.

Call (888) 203-2358

Powerhouse® is a registered trademark of its owner. HTD® is a registered trademark of Gates Corporation. All third-party part numbers and trademarks referenced are the property of their respective owners. References are for compatibility identification only and do not imply affiliation or endorsement.
