Description
60-5M09-6A5 Powerhouse® HTD Timing Pulley, 6 Teeth, 5M Pitch, 3/8 in Bore
The 60-5M09-6A5 is a 6-tooth 5 mm HTD® compatible timing pulley with a 3/8 in finished bore, machined from aluminum with a clear anodized finish, built for 9mm wide belts. Machined from solid stock, never sintered or powdered metal. Powerhouse® HTD pulleys fit drives using HTD® curvilinear belts of the same pitch and width.
$50 minimum order on drive components. Mix and match any pulleys, bushings, sheaves, sprockets, and accessories in your cart to reach the $50 minimum. Questions? Call (888) 203-2358.
Specifications

Dimension key for this construction type. Values for this part number are in the table below.
| Specification | Value |
|---|---|
| Part Number | 60-5M09-6A5 |
| Teeth | 6 |
| Pitch | 5 mm HTD® compatible |
| For Belt Width | 9mm |
| Pitch Diameter | 3.7596 in |
| Outside Diameter | 3.7146 in |
| Bore | 3/8 in finished bore |
| Face Width | 0.546 in |
| Overall Length | 0.937 in |
| Hub Diameter | 1.5 in |
| Construction | Standard Hub |
| Set Screws | 2 x 10-32 |
| Material | Aluminum (no sintered or powdered metal) |
| Finish | Clear Anodized |
| Weight | 0.679 lb |
| Country of Origin | United States. ISO 9001:2015 certified manufacturing. |
Applications
- HTD curvilinear belt drives on industrial equipment
- Conveyors, packaging, and warehouse automation
- Replacing worn pulleys on existing HTD drives
Belt Compatibility
The 60-5M09-6A5 runs 5 mm HTD® compatible belts in 9mm width. The pitch is standardized, so belt and pulley brands can be mixed.
Cross Reference
The 60-5M09-6A5 interchanges with these equivalent part numbers, per published manufacturer interchange data:
| Manufacturer | Equivalent Part Number |
|---|---|
| Gates® | P60-5M-09AL |
| Stock Drive Products (SDP/SI) | A 6A25-060NF0912 |
| Neuman | 60M5-L09M-6 |
| York | 60-5M-09 X 3/8 |
| Powerdrive | 60-5M09-6A5 |
Always verify dimensions and bore size before substituting part numbers across manufacturers.
Buying in bulk? Save on volume.
Multi-unit and OEM quantities qualify for volume discounts. Call or email for a quantity quote.
Frequently Asked Questions
What belts fit the 60-5M09-6A5 pulley?
5 mm HTD® compatible timing belts in 9mm width from any manufacturer. The pitch is standardized, so belt and pulley brands can be mixed.
Does the 60-5M09-6A5 replace the Gates P60-5M-09AL?
Yes. Published interchange data crosses the 60-5M09-6A5 directly to the Gates P60-5M-09AL, as well as Stock Drive Products A 6A25-060NF0912, Neuman 60M5-L09M-6, York 60-5M-09 X 3/8. Verify dimensions and bore before ordering.
Does the 60-5M09-6A5 ship from Houston?
Yes. Stock items ship same day from our Houston, Texas warehouse. Call (888) 203-2358 to confirm availability.
