60-5P09-6A5 Powerhouse® Timing Pulley, 6 Teeth, 5P Pitch, 3/8 in Bore


Price:
$ 26.23

Description

60-5P09-6A5 Powerhouse® Timing Pulley, 6 Teeth, 5P Pitch, 3/8 in Bore

The 60-5P09-6A5 is a 6-tooth 5 mm Powerhouse® curvilinear timing pulley with a 3/8 in finished bore, machined from aluminum with a clear anodized finish, built for 9mm wide belts. Machined from solid stock, never sintered or powdered metal. The Powerhouse® modified curvilinear profile carries roughly twice the load of a standard curvilinear pulley of the same size.

$50 minimum order on drive components. Mix and match any pulleys, bushings, sheaves, sprockets, and accessories in your cart to reach the $50 minimum. Questions? Call (888) 203-2358.

Specifications

Type 6 pulley construction dimension diagram

Dimension key for this construction type. Values for this part number are in the table below.

Specification Value
Part Number 60-5P09-6A5
Teeth 6
Pitch 5 mm Powerhouse® curvilinear
For Belt Width 9mm
Pitch Diameter 3.7596 in
Outside Diameter 3.7146 in
Bore 3/8 in finished bore
Face Width 0.546 in
Overall Length 0.937 in
Hub Diameter 1.5 in
Construction Standard Hub
Set Screws 2 x 10-32
Material Aluminum (no sintered or powdered metal)
Finish Clear Anodized
Weight 0.683 lb
Country of Origin United States. ISO 9001:2015 certified manufacturing.

Applications

  • Higher load synchronous drives in compact spaces
  • Industrial automation and conveyor drives
  • Packaging and material handling equipment

Belt Compatibility

The 60-5P09-6A5 runs 5 mm Powerhouse® curvilinear belts in 9mm width. The pitch is standardized, so belt and pulley brands can be mixed.

Cross Reference

The 60-5P09-6A5 interchanges with these equivalent part numbers, per published manufacturer interchange data:

Manufacturer Equivalent Part Number
Gates® P60-5MGT-09AL
Stock Drive Products (SDP/SI) A 6A55-060NF0912
Powerdrive 60-5P09-6A5

Always verify dimensions and bore size before substituting part numbers across manufacturers.

Buying in bulk? Save on volume.

Multi-unit and OEM quantities qualify for volume discounts. Call or email for a quantity quote.

Frequently Asked Questions

What belts fit the 60-5P09-6A5 pulley?

5 mm Powerhouse® curvilinear timing belts in 9mm width from any manufacturer. The pitch is standardized, so belt and pulley brands can be mixed.

Does the 60-5P09-6A5 replace the Gates P60-5MGT-09AL?

Yes. Published interchange data crosses the 60-5P09-6A5 directly to the Gates P60-5MGT-09AL, as well as Stock Drive Products A 6A55-060NF0912, Powerdrive 60-5P09-6A5. Verify dimensions and bore before ordering.

Does the 60-5P09-6A5 ship from Houston?

Yes. Stock items ship same day from our Houston, Texas warehouse. Call (888) 203-2358 to confirm availability.

Need a quote on 60-5P09-6A5?

Houston warehouse, same-day shipping on stock items.

Call (888) 203-2358

Powerhouse® is a registered trademark of its owner. HTD® is a registered trademark of Gates Corporation. All third-party part numbers and trademarks referenced are the property of their respective owners. References are for compatibility identification only and do not imply affiliation or endorsement.
