Description
60-8P12-1610 Powerhouse® Timing Pulley, 6 Teeth, 8P Pitch
The 60-8P12-1610 is a 6-tooth 8 mm Powerhouse® curvilinear timing pulley. It mounts with an industry-standard bushing, sold separately, machined from ductile iron with a black oxide finish, built for 12mm wide belts. Machined from solid stock, never sintered or powdered metal. The Powerhouse® modified curvilinear profile carries roughly twice the load of a standard curvilinear pulley of the same size.
Specifications

Dimension key for this construction type. Values for this part number are in the table below.
| Specification | Value |
|---|---|
| Part Number | 60-8P12-1610 |
| Teeth | 6 |
| Pitch | 8 mm Powerhouse® curvilinear |
| For Belt Width | 12mm |
| Pitch Diameter | 6.0153 in |
| Outside Diameter | 5.9613 in |
| Flange Diameter | 6.375 in |
| Bore | Accepts 1610 bushing (not included) |
| Face Width | 0.75 in |
| Overall Length | 1 in |
| Construction | Taper Lock Hub |
| Flange Material | Steel |
| Material | Ductile Iron (no sintered or powdered metal) |
| Finish | Black Oxide |
| Weight | 5.25 lb |
| Country of Origin | United States. ISO 9001:2015 certified manufacturing. |
Applications
- Higher load synchronous drives in compact spaces
- Industrial automation and conveyor drives
- Packaging and material handling equipment
Belt Compatibility
The 60-8P12-1610 runs 8 mm Powerhouse® curvilinear belts in 12mm width. The pitch is standardized, so belt and pulley brands can be mixed.
Cross Reference
The 60-8P12-1610 interchanges with these equivalent part numbers, per published manufacturer interchange data:
| Manufacturer | Equivalent Part Number |
|---|---|
| Martin | P608M12-1610 |
| Gates® | P60-8MGT-12 |
| Grainger | 809TY4 |
| Powerdrive | 60-8P12-1610 |
| Continental (ContiTech) | P60-8M-12-1610 |
Always verify dimensions and bore size before substituting part numbers across manufacturers.
Buying in bulk? Save on volume.
Multi-unit and OEM quantities qualify for volume discounts. Call or email for a quantity quote.
Frequently Asked Questions
What belts fit the 60-8P12-1610 pulley?
8 mm Powerhouse® curvilinear timing belts in 12mm width from any manufacturer. The pitch is standardized, so belt and pulley brands can be mixed.
Does the 60-8P12-1610 replace the Martin P608M12-1610?
Yes. Published interchange data crosses the 60-8P12-1610 directly to the Martin P608M12-1610, as well as Gates P60-8MGT-12, Grainger 809TY4, Powerdrive 60-8P12-1610. Verify dimensions and bore before ordering.
Does the 60-8P12-1610 ship from Houston?
Yes. Stock items ship same day from our Houston, Texas warehouse. Call (888) 203-2358 to confirm availability.
Need a quote on 60-8P12-1610?
Houston warehouse, same-day shipping on stock items.
Call (888) 203-2358Powerhouse® is a registered trademark of its owner. HTD® is a registered trademark of Gates Corporation. All third-party part numbers and trademarks referenced are the property of their respective owners. References are for compatibility identification only and do not imply affiliation or endorsement.
