60B19 Roller Chain Sprocket, #60 Chain, 19 Teeth, B Hub
The 60B19 is a 19-tooth sprocket for ANSI #60 roller chain with a B style hub, machined from steel. Machined from solid stock, never sintered or powdered metal, which matters on sprockets where tooth wear sets the replacement interval.
Specifications
| Specification | Value |
|---|---|
| Part Number | 60B19 |
| Chain Size | ANSI #60 |
| Teeth | 19 |
| Hub Style | B |
| Strands | 1 |
| Outside Diameter | 4.945 in |
| Pitch Diameter | 4.557 in |
| Bore | 3/4 in minimum plain bore |
| Maximum Bore | 2.375 in |
| Material | Steel (no sintered or powdered metal) |
| Weight | 3.92 lb |
| Country of Origin | China |
Applications
- Roller chain drives on conveyors and material handling equipment
- Agricultural machinery and implement drives
- Packaging machinery and light industrial drives
Chain Compatibility
ANSI #60 is a standardized roller chain size, so the 60B19 runs #60 chain from any manufacturer in the same pitch.
Cross Reference
The 60B19 interchanges with these equivalent part numbers, per published manufacturer interchange data:
| Manufacturer | Equivalent Part Number |
|---|---|
| Dodge® | 105089 |
| Martin | 60B19 |
| US Tsubaki | 60B19 |
| Regal Rexnord (Browning®) | 60B19 |
| Ametric | 60B19 |
| McMaster-Carr | 2590K84 |
| Powerdrive | 60B19 |
Always verify dimensions and bore size before substituting part numbers across manufacturers.
Buying in bulk? Save on volume.
Multi-unit and OEM quantities qualify for volume discounts. Call or email for a quantity quote.
Frequently Asked Questions
What chain does the 60B19 sprocket run?
ANSI #60 roller chain. The size is standardized, so #60 chain from any manufacturer fits.
Does the 60B19 replace the Dodge 105089?
Yes. Published interchange data crosses the 60B19 directly to the Dodge 105089, as well as Martin 60B19, US Tsubaki 60B19, Regal Rexnord 60B19. Verify dimensions and bore before ordering.
Does the 60B19 ship from Houston?
Yes. Stock items ship same day from our Houston, Texas warehouse. Call (888) 203-2358 to confirm availability.
