60XL037-6S5 Timing Pulley, 6 Teeth, XL Pitch, 3/8 in Bore


Price:
$ 60.16

Description

60XL037-6S5 Timing Pulley, 6 Teeth, XL Pitch, 3/8 in Bore

The 60XL037-6S5 is a 6-tooth XL (0.200 in trapezoidal) timing pulley with a 3/8 in finished bore, machined from ductile iron with a black oxide finish, built for 0.375 in wide belts. Machined from solid stock, never sintered or powdered metal.

Specifications

Type 6 pulley construction dimension diagram

Dimension key for this construction type. Values for this part number are in the table below.

Specification Value
Part Number 60XL037-6S5
Teeth 6
Pitch XL (0.200 in trapezoidal)
For Belt Width 0.375 in
Pitch Diameter 3.8197 in
Outside Diameter 3.7997 in
Bore 3/8 in finished bore
Face Width 0.563 in
Overall Length 1 in
Hub Diameter 1.5 in
Construction Standard Hub
Set Screws 2 x 1/4-20
Material Ductile Iron (no sintered or powdered metal)
Finish Black Oxide
Weight 1.847 lb
Country of Origin United States. ISO 9001:2015 certified manufacturing.

Applications

  • Instrumentation, office equipment, and precision positioning drives
  • 3D printers and desktop CNC equipment
  • Robotics, medical devices, and packaging machinery

Belt Compatibility

The 60XL037-6S5 runs XL (0.200 in trapezoidal) belts in 0.375 in width. The pitch is standardized, so belt and pulley brands can be mixed.

Cross Reference

The 60XL037-6S5 interchanges with these equivalent part numbers, per published manufacturer interchange data:

Manufacturer Equivalent Part Number
Martin 60XL037
TB Woods® 60XL037
Regal Rexnord (Browning®) 60XLB037S
Mitsuboshi 60XL037-6S5
McMaster-Carr 6495K732
Powerdrive 60XL037-6S5
Continental (ContiTech) 60XL037-MPB(MIN3/8) STEEL

Always verify dimensions and bore size before substituting part numbers across manufacturers.

Buying in bulk? Save on volume.

Multi-unit and OEM quantities qualify for volume discounts. Call or email for a quantity quote.

Frequently Asked Questions

What belts fit the 60XL037-6S5 pulley?

XL (0.200 in trapezoidal) timing belts in 0.375 in width from any manufacturer. The pitch is standardized, so belt and pulley brands can be mixed.

Does the 60XL037-6S5 replace the Martin 60XL037?

Yes. Published interchange data crosses the 60XL037-6S5 directly to the Martin 60XL037, as well as TB Woods 60XL037, Regal Rexnord 60XLB037S, Mitsuboshi 60XL037-6S5. Verify dimensions and bore before ordering.

Does the 60XL037-6S5 ship from Houston?

Yes. Stock items ship same day from our Houston, Texas warehouse. Call (888) 203-2358 to confirm availability.

Need a quote on 60XL037-6S5?

Houston warehouse, same-day shipping on stock items.

Call (888) 203-2358

All third-party part numbers and trademarks referenced are the property of their respective owners. References are for compatibility identification only and do not imply affiliation or endorsement.
