60XL037-6WA5 Timing Pulley, 6 Teeth, XL Pitch, 3/8 in Bore


Price:
$ 38.38

Description

60XL037-6WA5 Timing Pulley, 6 Teeth, XL Pitch, 3/8 in Bore

The 60XL037-6WA5 is a 6-tooth XL (0.200 in trapezoidal) timing pulley with a 3/8 in finished bore, machined from aluminum with a clear anodized finish, built for 0.375 in wide belts. Machined from solid stock, never sintered or powdered metal.

$50 minimum order on drive components. Mix and match any pulleys, bushings, sheaves, sprockets, and accessories in your cart to reach the $50 minimum. Questions? Call (888) 203-2358.

Specifications

Type 6W pulley construction dimension diagram

Dimension key for this construction type. Values for this part number are in the table below.

Specification Value
Part Number 60XL037-6WA5
Teeth 6
Pitch XL (0.200 in trapezoidal)
For Belt Width 0.375 in
Pitch Diameter 3.8197 in
Outside Diameter 3.7997 in
Bore 3/8 in finished bore
Face Width 0.563 in
Overall Length 1 in
Hub Diameter 1.5 in
Construction Lightened Pulley with Standard Hub
Set Screws 2 x 10-32
Flange Material Aluminum
Material Aluminum (no sintered or powdered metal)
Finish Clear Anodized
Weight 0.58 lb
Country of Origin United States. ISO 9001:2015 certified manufacturing.

Applications

  • Instrumentation, office equipment, and precision positioning drives
  • 3D printers and desktop CNC equipment
  • Robotics, medical devices, and packaging machinery
  • Weight-sensitive drives (webbed, lightened construction)

Belt Compatibility

The 60XL037-6WA5 runs XL (0.200 in trapezoidal) belts in 0.375 in width. The pitch is standardized, so belt and pulley brands can be mixed.

Cross Reference

The 60XL037-6WA5 interchanges with these equivalent part numbers, per published manufacturer interchange data:

Manufacturer Equivalent Part Number
Dodge® 60XL037-MPB
Gates® PB60XL037
TB Woods® 60XL037
Regal Rexnord (Browning®) 60XLB037
Mitsuboshi 60XL037-6WA5
Stock Drive Products (SDP/SI) A 6A 3-60NF03712
Jason Industrial 60XL037-5/16
Neuman 60XL037 X 3/8 6W
York 60XL037-3A X 3/8
McMaster-Carr 1277N61

Always verify dimensions and bore size before substituting part numbers across manufacturers.

Buying in bulk? Save on volume.

Multi-unit and OEM quantities qualify for volume discounts. Call or email for a quantity quote.

Frequently Asked Questions

What belts fit the 60XL037-6WA5 pulley?

XL (0.200 in trapezoidal) timing belts in 0.375 in width from any manufacturer. The pitch is standardized, so belt and pulley brands can be mixed.

Does the 60XL037-6WA5 replace the Dodge 60XL037-MPB?

Yes. Published interchange data crosses the 60XL037-6WA5 directly to the Dodge 60XL037-MPB, as well as Gates PB60XL037, TB Woods 60XL037, Regal Rexnord 60XLB037. Verify dimensions and bore before ordering.

Does the 60XL037-6WA5 ship from Houston?

Yes. Stock items ship same day from our Houston, Texas warehouse. Call (888) 203-2358 to confirm availability.

Need a quote on 60XL037-6WA5?

Houston warehouse, same-day shipping on stock items.

Call (888) 203-2358

All third-party part numbers and trademarks referenced are the property of their respective owners. References are for compatibility identification only and do not imply affiliation or endorsement.
