Description
6J236JA Poly-V Sheave, 6 Ribs, J Section, 2.36 in OD
The 6J236JA is a 6-rib J section Poly-V sheave with a 2.36 in outside diameter, machined from steel. It mounts with an industry-standard JA bushing, sold separately. Poly-V (multi-rib) drives run smoother and allow smaller diameters and higher speed ratios than classical V-belts.
Specifications
| Specification | Value |
|---|---|
| Part Number | 6J236JA |
| Belt Section | J |
| Ribs | 6 |
| Outside Diameter | 2.36 in |
| Pitch Diameter | 2.39 in |
| Bushing | JA series (not included) |
| Material | Steel (no sintered or powdered metal) |
| Finish | Black Oxide |
| Weight | 0.5 lb |
| Country of Origin | United States. ISO 9001:2015 certified manufacturing. |
Applications
- High speed ratio drives on compressors and machine tools
- Appliance, HVAC, and automotive accessory style drives
- Compact drives needing smooth, quiet power transmission
Cross Reference
The 6J236JA interchanges with these equivalent part numbers, per published manufacturer interchange data:
| Manufacturer | Equivalent Part Number |
|---|---|
| TB Woods® | 6J236 |
| Mitsuboshi | 6J236JA |
| Powerdrive | 6J236JA |
Always verify dimensions and bore size before substituting part numbers across manufacturers.
Buying in bulk? Save on volume.
Multi-unit and OEM quantities qualify for volume discounts. Call or email for a quantity quote.
Frequently Asked Questions
What belts run on the 6J236JA?
J section Poly-V (multi-rib) belts with up to 6 ribs engaged. The section is standardized across belt manufacturers.
Does the 6J236JA replace the TB Woods 6J236?
Yes. Published interchange data crosses the 6J236JA directly to the TB Woods 6J236, as well as Mitsuboshi 6J236JA, Powerdrive 6J236JA. Verify dimensions and bore before ordering.
Does the 6J236JA ship from Houston?
Yes. Stock items ship same day from our Houston, Texas warehouse. Call (888) 203-2358 to confirm availability.
All third-party part numbers and trademarks referenced are the property of their respective owners. References are for compatibility identification only and do not imply affiliation or endorsement.
