70-5M15M6A12 Powerhouse® HTD Timing Pulley, 7 Teeth, 5M Pitch, 12 mm Bore


Price:
$ 40.03

Description

70-5M15M6A12 Powerhouse® HTD Timing Pulley, 7 Teeth, 5M Pitch, 12 mm Bore

The 70-5M15M6A12 is a 7-tooth 5 mm HTD® compatible timing pulley with a 12 mm finished bore, machined from aluminum with a clear anodized finish, built for 15mm wide belts. Machined from solid stock, never sintered or powdered metal. Powerhouse® HTD pulleys fit drives using HTD® curvilinear belts of the same pitch and width.

$50 minimum order on drive components. Mix and match any pulleys, bushings, sheaves, sprockets, and accessories in your cart to reach the $50 minimum. Questions? Call (888) 203-2358.

Specifications

Type 6 pulley construction dimension diagram

Dimension key for this construction type. Values for this part number are in the table below.

Specification Value
Part Number 70-5M15M6A12
Teeth 7
Pitch 5 mm HTD® compatible
For Belt Width 15mm
Pitch Diameter 4.3862 in
Outside Diameter 4.3412 in
Bore 12 mm finished bore
Construction Standard Hub
Set Screws 2 x M6
Material Aluminum (no sintered or powdered metal)
Finish Clear Anodized
Weight 0.75 lb
Country of Origin United States. ISO 9001:2015 certified manufacturing.

Applications

  • HTD curvilinear belt drives on industrial equipment
  • Conveyors, packaging, and warehouse automation
  • Replacing worn pulleys on existing HTD drives

Belt Compatibility

The 70-5M15M6A12 runs 5 mm HTD® compatible belts in 15mm width. The pitch is standardized, so belt and pulley brands can be mixed.

Cross Reference

The 70-5M15M6A12 interchanges with these equivalent part numbers, per published manufacturer interchange data:

Manufacturer Equivalent Part Number
Stock Drive Products (SDP/SI) A 6A25M070NF1512
Powerdrive 70-5M15M6A12

Always verify dimensions and bore size before substituting part numbers across manufacturers.

Buying in bulk? Save on volume.

Multi-unit and OEM quantities qualify for volume discounts. Call or email for a quantity quote.

Frequently Asked Questions

What belts fit the 70-5M15M6A12 pulley?

5 mm HTD® compatible timing belts in 15mm width from any manufacturer. The pitch is standardized, so belt and pulley brands can be mixed.

Does the 70-5M15M6A12 replace the Stock Drive Products A 6A25M070NF1512?

Yes. Published interchange data crosses the 70-5M15M6A12 directly to the Stock Drive Products A 6A25M070NF1512, as well as Powerdrive 70-5M15M6A12. Verify dimensions and bore before ordering.

Does the 70-5M15M6A12 ship from Houston?

Yes. Stock items ship same day from our Houston, Texas warehouse. Call (888) 203-2358 to confirm availability.

Need a quote on 70-5M15M6A12?

Houston warehouse, same-day shipping on stock items.

Call (888) 203-2358

Powerhouse® is a registered trademark of its owner. HTD® is a registered trademark of Gates Corporation. All third-party part numbers and trademarks referenced are the property of their respective owners. References are for compatibility identification only and do not imply affiliation or endorsement.
