72-8P30-2517 Powerhouse® Timing Pulley, 72 Teeth, 8P Pitch


Price:
$ 250.68

Description

72-8P30-2517 Powerhouse® Timing Pulley, 72 Teeth, 8P Pitch

The 72-8P30-2517 is a 72-tooth 8 mm Powerhouse® curvilinear timing pulley. It mounts with an industry-standard bushing, sold separately, machined from ductile iron with a black oxide finish, built for 3mm wide belts. Machined from solid stock, never sintered or powdered metal. The Powerhouse® modified curvilinear profile carries roughly twice the load of a standard curvilinear pulley of the same size.

Specifications

Type B1F pulley construction dimension diagram

Dimension key for this construction type. Values for this part number are in the table below.

Specification Value
Part Number 72-8P30-2517
Teeth 72
Pitch 8 mm Powerhouse® curvilinear
For Belt Width 3mm
Pitch Diameter 7.2184 in
Outside Diameter 7.1644 in
Flange Diameter 7.575 in
Bore Accepts 2517 bushing (not included)
Face Width 1.5 in
Overall Length 1.75 in
Construction Taper Lock Hub
Flange Material Steel
Material Ductile Iron (no sintered or powdered metal)
Finish Black Oxide
Weight 12.736 lb
Country of Origin United States. ISO 9001:2015 certified manufacturing.

Applications

  • Higher load synchronous drives in compact spaces
  • Industrial automation and conveyor drives
  • Packaging and material handling equipment

Belt Compatibility

The 72-8P30-2517 runs 8 mm Powerhouse® curvilinear belts in 3mm width. The pitch is standardized, so belt and pulley brands can be mixed.

Cross Reference

The 72-8P30-2517 interchanges with these equivalent part numbers, per published manufacturer interchange data:

Manufacturer Equivalent Part Number
Dodge® P72-8M-30-2517
Martin P728M30-2517
Gates® P72-8MGT-30
TB Woods® P728M30TL
Regal Rexnord (Browning®) B728M30TL
Ametric 8M72TL30.2517
Grainger 809U08
Powerdrive 72-8P30-2517
Continental (ContiTech) P72-8M-30-2517

Always verify dimensions and bore size before substituting part numbers across manufacturers.

Buying in bulk? Save on volume.

Multi-unit and OEM quantities qualify for volume discounts. Call or email for a quantity quote.

Frequently Asked Questions

What belts fit the 72-8P30-2517 pulley?

8 mm Powerhouse® curvilinear timing belts in 3mm width from any manufacturer. The pitch is standardized, so belt and pulley brands can be mixed.

Does the 72-8P30-2517 replace the Dodge P72-8M-30-2517?

Yes. Published interchange data crosses the 72-8P30-2517 directly to the Dodge P72-8M-30-2517, as well as Martin P728M30-2517, Gates P72-8MGT-30, TB Woods P728M30TL. Verify dimensions and bore before ordering.

Does the 72-8P30-2517 ship from Houston?

Yes. Stock items ship same day from our Houston, Texas warehouse. Call (888) 203-2358 to confirm availability.

Need a quote on 72-8P30-2517?

Houston warehouse, same-day shipping on stock items.

Call (888) 203-2358

Powerhouse® is a registered trademark of its owner. HTD® is a registered trademark of Gates Corporation. All third-party part numbers and trademarks referenced are the property of their respective owners. References are for compatibility identification only and do not imply affiliation or endorsement.
