Description
85V1090F V-Belt Sheave, 8 Grooves, 5V Section, 10.9 in OD, F Bushing
The 85V1090F is a 8-groove 5V section narrow wedge V-belt sheave with a 10.9 in outside diameter, fully machined from cast iron and statically balanced. It mounts with an industry-standard F QD® style bushing, sold separately, sized to your shaft. It runs 5V and 5VX narrow wedge V-belts.
Specifications
| Specification | Value |
|---|---|
| Part Number | 85V1090F |
| Belt Section | 5V |
| Grooves | 8 |
| Outside Diameter | 10.9 in |
| Pitch Diameter | 10.8 in |
| Face Width | 5.8125 in |
| Bushing | F series, QD® style (not included) |
| Material | Cast Iron, fully machined, statically balanced |
| Weight | 63.1 lb |
| Country of Origin | China |
Applications
- Multi-belt narrow wedge drives on fans, blowers, and pumps
- HVAC air handlers and cooling tower drives
- Compressors and industrial process equipment
- Replacing worn sheaves on existing drives without changing belts or bushings
Cross Reference
The 85V1090F interchanges with these equivalent part numbers, per published manufacturer interchange data:
| Manufacturer | Equivalent Part Number |
|---|---|
| Dodge® | D8-5V109 |
| Martin | 8 5V 1090 F |
| Gates® | QD8/5V10.90 |
| TB Woods® | 5V1098 |
| Regal Rexnord (Browning®) | 85V1090F |
| Carlisle | 8-5V-1090-F |
| Masterdrive | 8/5V1090F |
| Maurey | 85V10.9-F |
| Jason Industrial | 8/5V1090F |
| Optibelt | QD 5V1090/8 F |
Always verify dimensions and bore size before substituting part numbers across manufacturers.
Buying in bulk? Save on volume.
Multi-unit and OEM quantities qualify for volume discounts. Call or email for a quantity quote.
Frequently Asked Questions
What belts run on the 85V1090F?
5V and 5VX narrow wedge V-belts. These sections are standardized, so any manufacturer's belts of the correct section and length will run in the grooves.
Does the 85V1090F replace the Dodge D8-5V109 sheave?
Yes. Published interchange data crosses the 85V1090F directly to the Dodge D8-5V109, as well as Martin 8 5V 1090 F, Gates QD8/5V10.90, TB Woods 5V1098. Verify groove count, diameter, and bore or bushing before ordering.
What bushing does the 85V1090F use?
A F series QD style bushing, sold separately. F is an industry-standard bushing size, so any manufacturer's standard F bushing fits. Order the bushing bore that matches your shaft diameter.
Does the 85V1090F ship from Houston?
Yes. Stock items ship same day from our Houston, Texas warehouse. Call (888) 203-2358 to confirm availability.
