AK41x15/16 Light Duty V-Belt Sheave, 1 Groove, 3.95 in OD, 15/16 in Bore


Price:
$ 24.16

Description

AK41x15/16 Light Duty V-Belt Sheave, 1 Groove, 3.95 in OD, 15/16 in Bore

The AK41x15/16 is a 1-groove light duty V-belt sheave with a 3.95 in outside diameter, fully machined from cast iron and statically balanced, supplied with a 15/16 in finished bore. It runs 3L, 4L, and A section V-belts.

$50 minimum order on drive components. Mix and match any pulleys, bushings, sheaves, sprockets, and accessories in your cart to reach the $50 minimum. Questions? Call (888) 203-2358.

Specifications

Specification Value
Part Number AK41x15/16
Belt Section AK
Grooves 1
Outside Diameter 3.95 in
Face Width 0.75 in
Bore 15/16 in finished bore
Keyway / Set Screw 1 x 5/16-18 UNC
Material Cast Iron, fully machined, statically balanced
Weight 1.7 lb
Country of Origin China

Applications

  • Fractional horsepower motor drives
  • Furnace blowers, attic fans, and air handlers
  • Power tools, lawn equipment, and light machinery
  • Direct replacement for worn FHP sheaves

Cross Reference

The AK41x15/16 interchanges with these equivalent part numbers, per published manufacturer interchange data:

Manufacturer Equivalent Part Number
Dodge® AK41 X 15/16
Martin AK41 15/16
Gates® AK41.15/16
TB Woods® AK4115/16
Regal Rexnord (Browning®) AK41x15/16
Carlisle AK-41-15/16
Masterdrive AK41-15/16
Maurey AK41 X 15/16
Jason Industrial AK41-15/16
Optibelt AK41-15/16

Always verify dimensions and bore size before substituting part numbers across manufacturers.

Buying in bulk? Save on volume.

Multi-unit and OEM quantities qualify for volume discounts. Call or email for a quantity quote.

Frequently Asked Questions

What belts run on the AK41x15/16?

3L, 4L, and A section V-belts. These sections are standardized, so any manufacturer's belts of the correct section and length will run in the grooves.

Does the AK41x15/16 replace the Dodge AK41 X 15/16 sheave?

Yes. Published interchange data crosses the AK41x15/16 directly to the Dodge AK41 X 15/16, as well as Martin AK41 15/16, Gates AK41.15/16, TB Woods AK4115/16. Verify groove count, diameter, and bore or bushing before ordering.

Does the AK41x15/16 ship from Houston?

Yes. Stock items ship same day from our Houston, Texas warehouse. Call (888) 203-2358 to confirm availability.

Need a quote on AK41x15/16?

Houston warehouse, same-day shipping on stock items.

Call (888) 203-2358

QD® is a registered trademark of TB Woods/Regal Rexnord. All third-party part numbers and trademarks referenced, including Dodge®, Gates®, Martin, TB Woods®, Browning®, and others shown in the cross reference table, are the property of their respective owners. References are for compatibility identification only and do not imply affiliation or endorsement.
