BK62x15/16 Light Duty V-Belt Sheave, 1 Groove, 5.95 in OD, 15/16 in Bore


Price:
$ 33.25

Description

BK62x15/16 Light Duty V-Belt Sheave, 1 Groove, 5.95 in OD, 15/16 in Bore

The BK62x15/16 is a 1-groove light duty V-belt sheave with a 5.95 in outside diameter, fully machined from cast iron and statically balanced, supplied with a 15/16 in finished bore. It runs 4L, 5L, A, and B section V-belts.

$50 minimum order on drive components. Mix and match any pulleys, bushings, sheaves, sprockets, and accessories in your cart to reach the $50 minimum. Questions? Call (888) 203-2358.

Specifications

Specification Value
Part Number BK62x15/16
Belt Section BK
Grooves 1
Outside Diameter 5.95 in
Pitch Diameter (A / B belts) 5.2 in / 5.6 in
Face Width 0.875 in
Bore 15/16 in finished bore
Keyway / Set Screw 1 x 5/16-18 UNC
Material Cast Iron, fully machined, statically balanced
Weight 2.6 lb
Country of Origin China

Applications

  • Fractional horsepower motor drives
  • Furnace blowers, attic fans, and air handlers
  • Power tools, lawn equipment, and light machinery
  • Direct replacement for worn FHP sheaves

Cross Reference

The BK62x15/16 interchanges with these equivalent part numbers, per published manufacturer interchange data:

Manufacturer Equivalent Part Number
Dodge® BK62 X 15/16
Martin BK62 15/16
Gates® BK62.15/16
TB Woods® BK6215/16
Regal Rexnord (Browning®) BK62x15/16
Carlisle BK-62-15/16
Masterdrive BK62-15/16
Maurey BK62 X 15/16
Jason Industrial BK62-15/16
Optibelt BK62-15/16

Always verify dimensions and bore size before substituting part numbers across manufacturers.

Buying in bulk? Save on volume.

Multi-unit and OEM quantities qualify for volume discounts. Call or email for a quantity quote.

Frequently Asked Questions

What belts run on the BK62x15/16?

4L, 5L, A, and B section V-belts. These sections are standardized, so any manufacturer's belts of the correct section and length will run in the grooves.

Does the BK62x15/16 replace the Dodge BK62 X 15/16 sheave?

Yes. Published interchange data crosses the BK62x15/16 directly to the Dodge BK62 X 15/16, as well as Martin BK62 15/16, Gates BK62.15/16, TB Woods BK6215/16. Verify groove count, diameter, and bore or bushing before ordering.

Why does the BK62x15/16 list two pitch diameters?

Combination sheaves run more than one belt section, and each section rides at a different depth in the groove. The BK62x15/16 has a 5.2 in pitch diameter with A or 4L belts and 5.6 in with B or 5L belts.

Does the BK62x15/16 ship from Houston?

Yes. Stock items ship same day from our Houston, Texas warehouse. Call (888) 203-2358 to confirm availability.

Need a quote on BK62x15/16?

Houston warehouse, same-day shipping on stock items.

Call (888) 203-2358

QD® is a registered trademark of TB Woods/Regal Rexnord. All third-party part numbers and trademarks referenced, including Dodge®, Gates®, Martin, TB Woods®, Browning®, and others shown in the cross reference table, are the property of their respective owners. References are for compatibility identification only and do not imply affiliation or endorsement.
