F168-14MX20-F Powerhouse® MX Timing Pulley, 168 Teeth, 14MX Pitch


Price:
$ 1,092.44

Description

Representative image shown. Actual product appearance varies by size, bore, and configuration. Refer to the specifications table for exact dimensions of this part number.

F168-14MX20-F Powerhouse® MX Timing Pulley, 168 Teeth, 14MX Pitch

The F168-14MX20-F is a 168-tooth 14 mm MX high torque timing pulley. It mounts with an industry-standard bushing, sold separately, machined from cast iron with a black oxide finish, built for 2mm wide belts. Machined from solid stock, never sintered or powdered metal. Powerhouse® MX pulleys run on the same high torque drives as Gates Poly Chain® GT® Carbon™ and Continental Synchrochain Carbon belts.

Specifications

Type C pulley construction dimension diagram

Dimension key for this construction type. Values for this part number are in the table below.

Specification Value
Part Number F168-14MX20-F
Teeth 168
Pitch 14 mm MX high torque
For Belt Width 2mm
Pitch Diameter 29.475 in
Outside Diameter 29.365 in
Bore Accepts F bushing (not included)
Face Width 1.359 in
Overall Length 2.5 in
Hub Diameter 9 in
Construction ACHE Sprocket with Quick Disconnect Hub
Material Cast Iron (no sintered or powdered metal)
Finish Black Oxide
Weight 102 lb
Country of Origin China

Applications

  • High torque, low speed drives replacing roller chain
  • Air cooled heat exchanger (ACHE) fan drives
  • Oil and gas pumping equipment
  • Material handling and conveyor drives
  • Weight-sensitive drives (webbed, lightened construction)

Belt Compatibility

The F168-14MX20-F runs 14 mm MX high torque belts in 2mm width. The pitch is standardized, so belt and pulley brands can be mixed.

Cross Reference

The F168-14MX20-F interchanges with these equivalent part numbers, per published manufacturer interchange data:

Manufacturer Equivalent Part Number
Dodge® F14MX-168S-20-F
Martin F14MX168S20-F
Gates® F14M-168S-20
Mitsuboshi F168-14MX20-F
Powerdrive F168-14MX20-F

Always verify dimensions and bore size before substituting part numbers across manufacturers.

Buying in bulk? Save on volume.

Multi-unit and OEM quantities qualify for volume discounts. Call or email for a quantity quote.

Frequently Asked Questions

What belts fit the F168-14MX20-F pulley?

14 mm MX high torque timing belts in 2mm width from any manufacturer. The pitch is standardized, so belt and pulley brands can be mixed.

Does the F168-14MX20-F replace the Dodge F14MX-168S-20-F?

Yes. Published interchange data crosses the F168-14MX20-F directly to the Dodge F14MX-168S-20-F, as well as Martin F14MX168S20-F, Gates F14M-168S-20, Mitsuboshi F168-14MX20-F. Verify dimensions and bore before ordering.

Does the F168-14MX20-F ship from Houston?

Yes. Stock items ship same day from our Houston, Texas warehouse. Call (888) 203-2358 to confirm availability.

Need a quote on F168-14MX20-F?

Houston warehouse, same-day shipping on stock items.

Call (888) 203-2358

Powerhouse® is a registered trademark of its owner. Poly Chain®, GT®, and Carbon™ are trademarks of Gates Corporation. Synchrochain is a trademark of Continental. All third-party part numbers and trademarks referenced are the property of their respective owners. References are for compatibility identification only and do not imply affiliation or endorsement.
