F234-14M55-F Powerhouse® HTD Timing Pulley, 234 Teeth, 14M Pitch


Price:
$ 2,165

Description

Representative image shown. Actual product appearance varies by size, bore, and configuration. Refer to the specifications table for exact dimensions of this part number.

F234-14M55-F Powerhouse® HTD Timing Pulley, 234 Teeth, 14M Pitch

The F234-14M55-F is a 234-tooth 14 mm HTD® compatible timing pulley. It mounts with an industry-standard bushing, sold separately, machined from cast iron with a black oxide finish, built for 55mm wide belts. Machined from solid stock, never sintered or powdered metal. Powerhouse® HTD pulleys fit drives using HTD® curvilinear belts of the same pitch and width.

Specifications

Type C pulley construction dimension diagram

Dimension key for this construction type. Values for this part number are in the table below.

Specification Value
Part Number F234-14M55-F
Teeth 234
Pitch 14 mm HTD® compatible
For Belt Width 55mm
Pitch Diameter 41.0545 in
Outside Diameter 40.9445 in
Bore Accepts F bushing (not included)
Face Width 2.75 in
Overall Length 2.75 in
Construction ACHE Sprocket with Quick Disconnect Hub
Material Cast Iron (no sintered or powdered metal)
Finish Black Oxide
Weight 196 lb
Country of Origin China

Applications

  • HTD curvilinear belt drives on industrial equipment
  • Conveyors, packaging, and warehouse automation
  • Replacing worn pulleys on existing HTD drives
  • Weight-sensitive drives (webbed, lightened construction)

Belt Compatibility

The F234-14M55-F runs 14 mm HTD® compatible belts in 55mm width. The pitch is standardized, so belt and pulley brands can be mixed.

Cross Reference

The F234-14M55-F interchanges with these equivalent part numbers, per published manufacturer interchange data:

Manufacturer Equivalent Part Number
Dodge® P234-14M-55-F
Powerdrive F234-14M55-F

Always verify dimensions and bore size before substituting part numbers across manufacturers.

Buying in bulk? Save on volume.

Multi-unit and OEM quantities qualify for volume discounts. Call or email for a quantity quote.

Frequently Asked Questions

What belts fit the F234-14M55-F pulley?

14 mm HTD® compatible timing belts in 55mm width from any manufacturer. The pitch is standardized, so belt and pulley brands can be mixed.

Does the F234-14M55-F replace the Dodge P234-14M-55-F?

Yes. Published interchange data crosses the F234-14M55-F directly to the Dodge P234-14M-55-F, as well as Powerdrive F234-14M55-F. Verify dimensions and bore before ordering.

Does the F234-14M55-F ship from Houston?

Yes. Stock items ship same day from our Houston, Texas warehouse. Call (888) 203-2358 to confirm availability.

Need a quote on F234-14M55-F?

Houston warehouse, same-day shipping on stock items.

Call (888) 203-2358

Powerhouse® is a registered trademark of its owner. HTD® is a registered trademark of Gates Corporation. All third-party part numbers and trademarks referenced are the property of their respective owners. References are for compatibility identification only and do not imply affiliation or endorsement.
