F30-14MX20-SK Powerhouse® MX Timing Pulley, 3 Teeth, 14MX Pitch


Price:
$ 165.27

Description

F30-14MX20-SK Powerhouse® MX Timing Pulley, 3 Teeth, 14MX Pitch

The F30-14MX20-SK is a 3-tooth 14 mm MX high torque timing pulley. It mounts with an industry-standard bushing, sold separately, machined from ductile iron with a black oxide finish, built for 2mm wide belts. Machined from solid stock, never sintered or powdered metal. Powerhouse® MX pulleys run on the same high torque drives as Gates Poly Chain® GT® Carbon™ and Continental Synchrochain Carbon belts.

Specifications

Type AF pulley construction dimension diagram

Dimension key for this construction type. Values for this part number are in the table below.

Specification Value
Part Number F30-14MX20-SK
Teeth 3
Pitch 14 mm MX high torque
For Belt Width 2mm
Pitch Diameter 5.2634 in
Outside Diameter 5.1534 in
Flange Diameter 5.76 in
Bore Accepts SK bushing (not included)
Face Width 1.359 in
Overall Length 1.359 in
Hub Diameter 4.8 in
Construction ACHE Sprocket with Quick Disconnect Hub
Flange Material Steel
Material Ductile Iron (no sintered or powdered metal)
Finish Black Oxide
Weight 4.784 lb
Country of Origin United States. ISO 9001:2015 certified manufacturing.

Applications

  • High torque, low speed drives replacing roller chain
  • Air cooled heat exchanger (ACHE) fan drives
  • Oil and gas pumping equipment
  • Material handling and conveyor drives

Belt Compatibility

The F30-14MX20-SK runs 14 mm MX high torque belts in 2mm width. The pitch is standardized, so belt and pulley brands can be mixed.

Cross Reference

The F30-14MX20-SK interchanges with these equivalent part numbers, per published manufacturer interchange data:

Manufacturer Equivalent Part Number
Dodge® F14MX-30S-20-SK
Martin F14MX30S20-SK
Gates® F14M-30S-20
Mitsuboshi F30-14MX20-SK
Powerdrive F30-14MX20-SK
Continental (ContiTech) 30G-14M-20-SK AXIAL FAN SPROCKET/IDLER

Always verify dimensions and bore size before substituting part numbers across manufacturers.

Buying in bulk? Save on volume.

Multi-unit and OEM quantities qualify for volume discounts. Call or email for a quantity quote.

Frequently Asked Questions

What belts fit the F30-14MX20-SK pulley?

14 mm MX high torque timing belts in 2mm width from any manufacturer. The pitch is standardized, so belt and pulley brands can be mixed.

Does the F30-14MX20-SK replace the Dodge F14MX-30S-20-SK?

Yes. Published interchange data crosses the F30-14MX20-SK directly to the Dodge F14MX-30S-20-SK, as well as Martin F14MX30S20-SK, Gates F14M-30S-20, Mitsuboshi F30-14MX20-SK. Verify dimensions and bore before ordering.

Does the F30-14MX20-SK ship from Houston?

Yes. Stock items ship same day from our Houston, Texas warehouse. Call (888) 203-2358 to confirm availability.

Need a quote on F30-14MX20-SK?

Houston warehouse, same-day shipping on stock items.

Call (888) 203-2358

Powerhouse® is a registered trademark of its owner. Poly Chain®, GT®, and Carbon™ are trademarks of Gates Corporation. Synchrochain is a trademark of Continental. All third-party part numbers and trademarks referenced are the property of their respective owners. References are for compatibility identification only and do not imply affiliation or endorsement.
