Description
F36-14MX-37-40-SF Powerhouse® HTD Timing Pulley, 36 Teeth, 14M Pitch
The F36-14MX-37-40-SF is a 36-tooth 14 mm HTD® compatible timing pulley. It mounts with an industry-standard bushing, sold separately, machined from ductile iron with a black oxide finish, built for 4mm wide belts. Machined from solid stock, never sintered or powdered metal. Powerhouse® HTD pulleys fit drives using HTD® curvilinear belts of the same pitch and width.
Specifications
| Specification | Value |
|---|---|
| Part Number | F36-14MX-37-40-SF |
| Teeth | 36 |
| Pitch | 14 mm HTD® compatible |
| For Belt Width | 4mm |
| Pitch Diameter | 6.3161 in |
| Outside Diameter | 6.2061 in |
| Flange Diameter | 6.816 in |
| Bore | Accepts SF bushing (not included) |
| Face Width | 2.125 in |
| Overall Length | 2.125 in |
| Material | Ductile Iron (no sintered or powdered metal) |
| Finish | Black Oxide |
| Weight | 9 lb |
| Country of Origin | China |
Applications
- HTD curvilinear belt drives on industrial equipment
- Conveyors, packaging, and warehouse automation
- Replacing worn pulleys on existing HTD drives
Belt Compatibility
The F36-14MX-37-40-SF runs 14 mm HTD® compatible belts in 4mm width. The pitch is standardized, so belt and pulley brands can be mixed.
Cross Reference
The F36-14MX-37-40-SF interchanges with these equivalent part numbers, per published manufacturer interchange data:
| Manufacturer | Equivalent Part Number |
|---|---|
| Dodge® | F14MX-36X-37-SK |
| Gates® | F14M-36S-37 |
| Powerdrive | F36-14MX-37-40-SF |
Always verify dimensions and bore size before substituting part numbers across manufacturers.
Buying in bulk? Save on volume.
Multi-unit and OEM quantities qualify for volume discounts. Call or email for a quantity quote.
Frequently Asked Questions
What belts fit the F36-14MX-37-40-SF pulley?
14 mm HTD® compatible timing belts in 4mm width from any manufacturer. The pitch is standardized, so belt and pulley brands can be mixed.
Does the F36-14MX-37-40-SF replace the Dodge F14MX-36X-37-SK?
Yes. Published interchange data crosses the F36-14MX-37-40-SF directly to the Dodge F14MX-36X-37-SK, as well as Gates F14M-36S-37, Powerdrive F36-14MX-37-40-SF. Verify dimensions and bore before ordering.
Does the F36-14MX-37-40-SF ship from Houston?
Yes. Stock items ship same day from our Houston, Texas warehouse. Call (888) 203-2358 to confirm availability.
Need a quote on F36-14MX-37-40-SF?
Houston warehouse, same-day shipping on stock items.
